Polaris RZR Pro XP 2020 Fuse Box Info
Passenger compartment fuse box location A:
The fuse box A is beneath the armrest and can be accessed by removing the bed of the armrest storage compartment (For two-seat vehicles). The fuse box A is in the rear center console and can be accessed by removing the cover (For four-seat vehicles).
Passenger compartment fuse box location B:
The fuse box B is located under the dash, near the operator’s right knee area.
Fuse Box Diagram | Layout
Passenger compartment fuse box A:
| Fuse/Relay | Rating | Functions |
| FAN | 30A | Engine Cooling Fan |
| PDM1 | 40A | Power to Secondary Fuse Center for Lights, Instrumentation, Audio Amp Fuse, and Accessory Relay |
| PDM2 | 30A | Power to Secondary Fuse Center for Auxiliary Outlets, Chassis, SCM, and Shock Fuse |
| PDM3 | 30A | Power to Secondary Fuse Center for Fuel, LCAC, and EFI Fuse |
| EPS | 30A | Electronic Power Steering |
| VREG1 | 40A | Voltage Regulator (Left) |
| VREG1 | 40A | Voltage Regulator (Right) |
| PULSE PWR | 200A | Battery Power to Polaris Pulse and 6AWG Cable |
Passenger compartment fuse box B:
| Fuse/Relay | Rating | Functions |
| LCAC | 7.5A | Water Pump |
| FUEL | 10A | Fuel Pump |
| TERM BLK | 10A | Terminal Block Accessory |
| INST ACCY | 5A | Diagnostic Accessory, Interior LED Light, Display Accessory (optional) |
| PWR PT 1 | 10A | 12V Socket (in front of gear selector) |
| EPS | 30A | Power Steering |
| INST UNSW | 7.5A | Display (optional), Gauge, Diagnostic |
| LIGHTS | 7.5A | Headlights, Taillights, Accent Lights (optional), Brake Lights |
| CHASSIS | 7.5A | AWD Switch Light, Oxygen Sensor Heater, EPS Wake-Up, Vehicle Speed Sensor, Seat Belt Switch, SCM Wake-Up (optional), SCM Mode Switch (optional), AWD Coil, Gauge, Waste Gate |
| EFI | 10A | Accessory Relay Coil, ECM Wake-Up, Pump Relay Coil, Chassis Relay Coil, Start Relay Coil, EFI Relay Coil, Injectors, SCM Relay Coil (optional), Lights Relay Coil, Ignition Coil, Starter Solenoid Coil, Brake Relay Coil |
| COIL | 7.5A | Coil on Plug |
| Additional Fuses (if equipped) | ||
| SCM | 5A | Shock Control Module |
| SHOCK | 5A | Shock Power |
| AUD AMP | 15A | Audio Amplifier |
