Abarth Punto Evo 2012 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Right dipped headlamp |
| 2 | 5A | Courtesy light, boot light, glove compartment light |
| 3 | 5A | Instrument panel |
| 4 | 20A | Door locking/unlocking motors, dead lock activation motors, boot unlocking motor |
| 5 | 10A | Supply and battery for EOBD diagnosis, automatic climate control unit, alarm, radio, Blue&Me™ control unit |
| 6 | 20A | Windscreen/rear window washer pump |
| 7 | 20A | Passenger side front electric window motor |
| 8 | 7.5A | Left dipped beam headlight, headlight alignment corrector |
| 10 | 7.5A | INT supply for brake pedal switch (NC contact), clutch pedal switch, interior heating unit, Blue&Me™ control unit, sound system wiring, voltage stabiliser control unit, reverse light on bumper, brake servo sensor, relay switch coils on engine compartment fusebox |
| 11 | 5A | INT supply for instrument panel, switch on brake pedal (NO contact), third brake light |
| 12 | 5A | INT supply for dashboard control lights, TMPS tyre pressure measurement control unit, electric wing mirror movement,sunroof control unit, my-port infotelematic system socket, electrochromic rear view mirror |
| 13 | 5A | INT/A supply for switch coils on engine fuse box and relay switch coils on body computer control unit |
| 14 | 20A | Driver’s front electric window motor |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 09 | 20A | Hi-Fi sound system with radio, control unit and subwoofer |
| 10 | 10A | Horn |
| 14 | 15A | Left main beam headlamp, right main beam headlamp |
| 19 | 7.5A | Air climate control compressor |
| 20 | 30A | Heated rear window |
| 21 | 15A | Fuel pump on tank |
| 30 | 15A | Left fog light, right fog light |
| 85 | - | Socket (set-up) |
| 86 | 15A | Passenger compartment socket, cigar lighter |
| 87 | 5A | Battery charge status sensor |
| 88 | 7.5A | Demister on driver-side door mirror, demister on passenger-side door mirror |
Luggage compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 01 | - | Free |
| 02 | - | Free |
| 03 | - | Free |
| 04 | - | Free |
| 05 | 15A | Boot socket |
| 06 | - | Free |
| 07 | - | Free |
| 08 | - | Free |
| 09 | - | Free |
| 13 | 5A | TPMS (tyre pressure monitoring system) control unit |
| 14 | 7.5A | Alarm system management control unit |
| 15 | - | Free |
| 16 | - | Free |
| 17 | 20A | Sunroof opening system |
