Acura NSX 2018 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box A is located under the dashboard on the driver’s side.
The interior fuse box B is located on the passenger’s side under glove box, under cover.
The interior fuse box C is located near the rear center speaker, behind the driver’s seat.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Passenger’s Door Handle |
| 2 | 15A | Door Lock |
| 3 | 7.5A | SMART |
| 4 | - | - |
| 5 | 20A | Front Accessory Power Socket |
| 6 | 20A | Fuel Pump |
| 7 | 15A | MISS SOL |
| 8 | 7.5A | ENG |
| 9 | 7.5A | VSA/ABS |
| 10 | 10A | SRS |
| 11 | 10A | Power System 2 |
| 12 | - | - |
| 13 | 10A | Power System 1 |
| 14 | 7.5A | Fuel Lid |
| 15 | (20A) | Driver’s Power Seat Reclining* |
| 16 | (7.5A) | - |
| 17 | (20A) | Seat Heater* |
| 18 | 10A | Driver’s Door Handle |
| 19 | - | - |
| 20 | 7.5A | Passenger’s Side Door Unlock |
| 21 | 7.5A | Daytime Running Lights |
| 22 | 7.5A | Key Lock |
| 23 | 7.5A | Air Conditioning |
| 24 | 7.5A | Feed Back IG1a |
| 25 | 7.5A | Instrument Panel Lights |
| 26 | (7.5A) | Power Lumbar Support* |
| 27 | 7.5A | Parking Lights |
| 28 | 15A | Sub Main |
| 29 | 10A | Meter |
| 30 | 7.5A | DR2 |
| 31 | 15A | Sub Fuel Pump |
| 32 | 10A | SRS |
| 33 | 7.5A | Passenger’s Side Door Lock |
| 34 | 7.5A | Driver’s Door Lock |
| 35 | 7.5A | Driver’s Door Unlock |
| 36 | (20A) | Driver’s Power Seat Sliding* |
| 37 | 7.5A | Right Daytime Running Light |
| 38 | 7.5A | Left Daytime Running Light |
| 39 | 7.5A | Feed Back IG1b |
| 40 | 7.5A | ACC |
| 41 | - | - |
| 42 | - | - |
* Not available on all models
Passenger compartment fuse box B:
| Fuse/Relay N° | Rating | Functions |
| a | (20A) | Passenger’s Power Seat Sliding* |
| b | (20A) | Passenger’s Power Seat Reclining* |
| c | (10A) | - |
| d | - | - |
| e | 7.5A | Wiper |
| f | 7.5A | EPS |
| g | 7.5A | DR1 |
| h | 7.5A | Power System 3 |
* Not available on all models
Passenger compartment fuse box C:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | HCA-2 |
| 2 | - | - |
| 3 | - | - |
| 4 | - | - |
| 5 | 20A | HCA-1 |
| 6 | 20A | DI-INJ |
| 7 | - | - |
| 8 | 30A | TCU |
* Not available on all models
Engine compartment fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 |
70A 50A 40A 20A 30A 200A |
EPS Cooling Fan ABS/VSA Motor ABS/VSA FSR AS F/B Main Main Fuse |
| 2 |
(50A) 60A (60A) (50A) 30A 30A (40A) 30A 30A (40A) |
- F/B Main 1 - - Left Electric Parking Brake Motor Right Electric Parking Brake Motor - Heater Motor 2 Heater Motor 1 - |
| 3 |
30A (30A) 30A (30A) |
E-OP - ADS AMP* |
| 4 | 10A | Parking Light |
| 5 | 7.5A | IGPS PCS |
| 6 | 10A | Left Headlight High Beam |
| 7 | 7.5A | VFP2 |
| 8 | 10A | Left Headlight Low Beam |
| 9 | 10A | Right Headlight High Beam |
| 10 | 10A | Right Headlight Low Beam |
| 11 | 7.5A | IGPS Fan |
| 12 | 15A | FI Main |
| 13 | 20A | FI Sub |
| 14 | 7.5A | Back Up |
| 15 | 7.5A | SBW ECU |
| 16 | 15A | DBW1 |
| 17 | 15A | IG Coil |
| 18 | 15A | DBW2 |
| 19 | 20A | Parking Light & Headlight Main |
| 20 | 20A | Rear Defroster |
| 21 | 20A | Front Washer |
| 22 | 15A | ISC |
| 23 | - | - |
| 24 | 10A | ACC/IG2 Main |
| 25 | 10A | Daytime Running Lights |
| 26 | 10A | Horn |
| 27 | 7.5A | Interior Lights |
| 28 | 15A | IGP2 |
| 29 | 10A | Audio |
* Not available on all models
Engine compartment fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 1 |
60A - 60A 30A 30A 30A 30A 40A |
SBW - F/B Main 2 Wiper Passenger Power Window IG Main 1 Driver Power Window ESB |
| 2 | 30A | IG Main 2 |
| 3 | 20A | IMA Motor |
| 4 | 7.5A | BMS |
| 5 | 7.5A | Stop |
| 6 | 20A | Turbo W/G |
| 7 | 7.5A | Hazard |
| 8 | 10A | A/C W/P |
| 9 | - | - |
| 10 | 7.5A | AEV |
| 11 | 7.5A | FI-ECU Backup |
| 12 | - | - |
| 13 | - | - |
| 14 | - | - |
| 15 | - | - |
| 16 | - | - |
| 17 | 10A | IMA Motor |
* Not available on all models
