Acura TL 2012 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box A is located under the dashboard on the driver’s side. The interior fuse box B is located on the lower passenger’s side panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box A (Driver’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Blind Spot Information System* |
| 2 | 7.5A | SH-AWD* |
| 3 | 20A | Washer |
| 4 | 7.5A | Wiper |
| 5 | 7.5A | ODS |
| 6 | 7.5A | ABS/VSA |
| 7 | - | Not Used |
| 8 | 7.5A | Starter Relay |
| 9 | 20A | Fuel Pump |
| 10 | 10A | VB SOL |
| 11 | 10A | SRS |
| 12 | 7.5A | Meter |
| 13 | 15A | ACG |
| 14 | - | Not Used |
| 15 | 7.5A | Daytime Running Light |
| 16 | 7.5A | A/C |
| 17 | 7.5A | Accessory, Key, Lock* |
| 18 | 7.5A | Accessory |
| 19 | 20A | Driver’s Power Seat Sliding |
| 20 | 20A | Moonroof |
| 21 | 20A | Driver’s Power Seat Reclining |
| 22 | 20A | Rear Left Power Window |
| 23 | 15A | Front ACC Socket |
| 24 | 20A | Driver’s Power Window |
| 25 | 15A | Driver’s Side Door Lock |
| 26 | 10A | Front Left Fog Light |
| 27 | 10A | Left Side Small Lights (Exterior) |
| 28 | 10A | Left Headlight High Beam |
| 29 | 7.5A | TPMS |
| 30 | 15A | Left Headlight Low Beam |
| 31 | - | Not Used |
| 32 | 7.5A | STS* |
* If equipped
Passenger compartment fuse box B (Passenger’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Right Headlight High Beam |
| 2 | 10A | Right Side Small Lights (Exterior) |
| 3 | 10A | Right Front Fog Light |
| 4 | 15A | Right Headlight Low Beam |
| 5 | - | Not Used |
| 6 | 7.5A | Interior Lights |
| 7 | - | Not Used |
| 8 | 20A | Passenger’s Power Seat Reclining |
| 9 | 20A | Passenger’s Power Seat Sliding |
| 10 | 10A | Right Side Door Lock |
| 11 | 20A | Rear Passenger’s Side Power Window |
| 12 | 10A | Keyless Access System* |
| 13 | 20A | Front Passenger’s Power Window |
| 14 | - | Not Used |
| 15 | 20A | Premium amplifier |
| 16 | 15A | Console ACC Socket |
| 17 | - | Not Used |
| 18 | 7.5A | Lumbar Support |
| 19 | 20A | Seat Heater |
| 20 | - | Not Used |
| 21 | - | Not Used |
| 22 | - | Not Used |
* If equipped
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1-1 | 120A | Battery |
| 1-2 | 40A | Passenger’s Side Fuse Box |
| 2-1 | 70A | EPS |
| 2-2 | 40A | ABS/VSA MTR |
| 2-3 | 30A | ABS/VSA |
| 2-4 | 40A | Passenger’s Side Fuse Box Option |
| 2-5 | 30A | Headlight Washer* |
| 2-6 | 30A | SH-AWD*1 |
| 3-1 | 50A | IG Main |
| 3-2 | 40A | Sub Fan Motor*1 |
| 3-3 | 30A | Sub Fan Motor*2 |
| 3-4 | 60A | Driver’s Side Fuse Box |
| 3-5 |
40A*1 30A*2 |
Main Fan Motor |
| 3-6 | 30A | Driver’s Side Light Main |
| 3-7 | 30A | Wiper Motor |
| 3-8 | 30A | Passenger’s Side Light Main |
| 4 | 40A | Rear Defroster |
| 5 | - | Not Used |
| 6 | - | Not Used |
| 7 | - | Not Used |
| 8 | 40A | Heater Motor |
| 9 | 15A | Hazard |
| 10 | 20A | Horn and Stop |
| 11 | 7.5A | Keyless Access System*1 |
| 12 | 7.5A | BMS (Battery Management System) |
| 13 | 15A | IG Coil |
| 14 | 15A | FI Sub |
| 15 | 10A | Back Up |
| 16 | 7.5A | Interior Lights |
| 17 | 15A | FI Main |
| 18 | 15A | DBW |
| 19 | 7.5A | Back Up FI ECU |
| 20 | 7.5A | MG, Clutch |
| 21 | 7.5A | Radiator Fan Timer |
* If equipped
*1 SH-AWD models only
*2 2WD models only
