Acura RL 2011 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box A is located on the lower driver’s side panel. The internal fuse box B is located on the right side of the steering wheel, under the dashboard. The interior fuse box C is located on the lower passenger’s side panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box A (Driver’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Drive by Wire |
| 2 | 15A | Ignition coil |
| 3 | 10A | Daytime running light |
| 4 | 15A | LAF heater |
| 5 | 7.5A | Radio |
| 6 | 7.5A | Interior light |
| 7 | 10A | Back-up |
| 8 | 20A | Door lock |
| 9 | 20A | Accessory socket |
| 10 | 7.5A | Occupant position detection system (OPDS) |
| 11 | 7.5A | Wiper |
| 12 | 15A | Rear heated seat |
| 13 | 20A | Passenger’s power seat reclining |
| 14 | 20A | Driver’s power seat sliding |
| 15 | 7.5A | Tire pressure monitoring system (TPMS) |
| 16 | 20A | Driver’s power seat reclining |
| 17 | 20A | Passenger’s power seat sliding |
| 18 | 15A | ACG |
| 19 | 20A | Fuel Pump |
| 20 | 15A | IGN SOL |
| 21 | 7.5A | Meter |
| 22 | 10A | SRS |
| 23 | 7.5A | IGP (PGM-FI ECU) |
| 24 | 20A | Left rear power window |
| 25 | 20A | ETS (telescopic) |
| 26 | 20A | ETS (tilt) |
| 27 | 30A | Driver’s power window |
| 28 | 20A | Moonroof |
| 29 | 7.5A | Adaptive Front Lighting System |
| 30 | 7.5A | Air Conditioner |
| 31 | 7.5A | e-pretensioner |
| 32 | 10A | ACC |
| 33 | - | Not Used |
Passenger compartment fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Starter diag. |
| 2 | 7.5A | Starter signal |
Passenger compartment fuse box C (Passenger’s side):
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | SH-AWD |
| 2 | 30A | Premium amplifier |
| 3 | 30A | Passenger’s power window |
| 4 | 30A | Driver’s automatic seat belt tensioner/e-pretensioner |
| 5 | 20A | Right rear power window |
| 6 | 20A | Heated seats |
| 7 | 7.5A | Illumination lights |
| 8 | 30A | Passenger’s automatic seat belt tensioner/e-pretensioner |
| 9 | 7.5A | Air conditioner |
Engine compartment fuse box (Primary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Left headlight low beam |
| 2 | 30A | Rear defroster coil |
| 3 | 10A | Left headlight high beam |
| 4 | 15A | Small light |
| 5 | 10A | Right headlight high beam |
| 6 | 15A | Right headlight low beam |
| 7 | 7.5A | Back-up |
| 8 | 15A | FI ECU |
| 9 | 30A | Wiper |
| 10 | 30A | Headlight washer* |
| 11 | 20A | Fog lights |
| 12 | 7.5A | MG clutch |
| 13 | 15A | Horn, Stop |
| 14 | 40A | Rear defroster |
| 15 | 40A | Back-up, ACC |
| 16 | 15A | Hazard |
| 17 | 30A | ABS/VSA motor |
| 18 | 40A | ABS/VSA |
| 19 | 40A | Option |
| 20 | 40A | Option |
| 21 | 40A | Heater motor |
| 22 |
70A 120A |
Passenger’s fuse box Battery |
| 23 |
50A 50A |
IG main Power window |
* Not available on all models
Engine compartment fuse box (Secondary) - fuse box is on the battery:
| Fuse/Relay N° | Rating | Functions |
| 1 | 50A | Radiator fan |
