Chevrolet Tracker 2003 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located under the left side of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay | Functions |
| P/W | Power Windows |
| DOM | Dome Light, Radio Memory |
| TAIL | License Plate Light, Clearance/Marker Lights, Instrument Panel Illumination, Warning Tone |
| HAZ | Hazard Lights, Turn Signal |
| IG | Oxygen Sensor Heater, Cruise Control, Ignition Coil, Meter, G Sensor |
| CIG | Cigar Lighter, Radio, Power Mirror |
| D/L | Door Locks |
| STP | Brake Light, Horn, Center High-Mounted Stop Lamp, Cruise Control |
| FOG | Not Used |
| DEF | Rear Window Defogger, DRL, Heater, Air Conditioning |
| S/H | Not Used |
| TRN | Turn Signal, Back-Up Light, Hazard Lights |
| WIP | Windshield Wiper/Washer, Rear Window Wiper/Washer |
Engine compartment fuse box:
| Fuse/Relay | Functions |
| 1 | Accessory Power Outlet |
| 2 | Electronic Fuel Injection System |
| 3 | Right Headlamp |
| 4 | Left Headlamp, High-Beam Indicator |
| 5 | Heater |
| 6 | Hazard Lamps, Rear Combination Lamps, Dome Light, Horn |
| 7 | Cigar Lighter, Radio, I.G. Coil, Meter, Wiper, Washer, Rear Defroster, Turn Signals, Back-Up Lamps |
| 8 | Anti-Lock Brake System |
| 9 | All Electrical Loads |
| 10 | Shift Lock (Relay |
| 11 (2.5L Engine Only) | Horn (Relay) |
| 12 | Air Conditioning Compressor (Relay |
| 13 | Air Conditioning Condenser Fan (Relay) |
| 14 | Air Conditioning |
