Chevrolet Blazer EV 2024 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is on the passenger side of the instrument panel, between the glove box and the door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | - |
| 2 | APO/CIGAR LTR – Auxiliary Power Outlet Instrument Panel/Cigar Lighter |
| 3 | - |
| 4 | USB PORT/APO AC 150W – Universal Serial Bus Port/Auxiliary Power Outlet Alternating Current 150W |
| 5 | STRG COL LOCK – RUN/CRANK Steering Column Lock |
| 6 | ELM 1– Exterior Lighting Module 1 |
| 7 | AMP-BASE – Amplifier-Base |
| 8 | RT DR LATCH – Right Door Latch |
| 9 | LT DR LATCH – Left Door Latch |
| 10 | STRG COL POS MDL – Steering Column Position Module |
| 11 | ACP 4 –ADAS Compute Platform 4 |
| 12 | - |
| 13 | EUROPE-TRLR CON & ECP_E/ECP_S/VICM – RUN/CRANK Europe – Trailer Control and Electrification Control Processor (Traction Power Inverter 1 and 2)/Vehicle Integration Control Module |
| 14 | HEADLAMPS – RUN/CRANK Headlamps |
| 15 | HDLP RT –Headlamp Right |
| 16 | STRG COL/CLOCK SPRING – Steering Column Lock/Clock Spring |
| 17 | SEAT FAN PASS & SEAT FAN DRVR – RUN/CRANK Seat Fan Passenger and Seat Fan Driver |
| 18 | VCD & SRR –Virtual Cockpit Display and Short Range Radar |
| 19 | MISC 2 & MISC 1 – RUN/CRANK Miscellaneous 2 Switch Bank/Electronic Toll Collection/Interior Particulate Matter Sensor/ Reflective Light Auxiliary Display and Miscellaneous 1 Electronic Brake Control Module/Exterior Lighting Module/Sensing and Diagnostic Module/Inside Rear View Mirror |
| 20 | BCM 1 & VICM – Body Control Module 1 and Vehicle Integration Control Module |
| 21 | LRR-RR & EPBS/ESM – Long Range Radar – Rear and Electric Park Brake Switch/Electronic Transmission Range Select Shifter Module |
| 22 | VKM/VKMB/AUX JACK & ACP3 – Virtual Key Module/Virtual Key Backup Module/Auxiliary Jack and ADAS Compute Platform 3 |
| 23 | T/LAMP RT & T/LAMP LT – Tail Lamp Right and Tail Lamp Left |
| 24 | UPA/APA/SBZA & SDM/AOS – Universal Park Assist/Automatic Park Assist/Side Blind Zone Alert and Sensing Diagnostic Module/Automatic Occupant Sensing Module |
| 25 | ACP 2/EOCM_LC/FCM/MFC & DMS/CGM/DLC/VDM – ADAS Compute Platform 2/External Object Calculating Module/Front Camera Module/Multi Function Control and Driver Monitoring System/Central Gateway Module/Diagnostic Link Connector/ Vehicle Data Monitor |
| 26 | ECP_E_BATT 2/ACEC & HUD/HVAC DISPLAY – Electrification Control Processor Battery 2/Air Condition Electric Compressor and Heads-Up Display/Heating,Ventilation and Air Conditioning Display |
| 27 | BCM 3 – Body Control Module 3 |
| 28 | BCM 2 – Body Control Module 2 |
| 29 | AMP-UPLEVEL - Amplifier - Uplevel |
| 30 | BCM 4 – Body Control Module 4 |
| 31 | VPM/SD CARD/ILSS/OHC – Video Processing Module/SD Card/Indicator Light and Solar Sensor/Over Head Console |
| 32 | HSWM – Heated Steering Wheel Module |
| 33 | LRR FR/LIDAR – Long Range Radar Front/Light Detection and Ranging |
| 34 | ELM 2 – Exterior Lighting Module 2 |
| 35 | HDLP LT – Headlamp Left |
| 36 | VCU BATT 1 – Virtual Cockpit Unit Battery 1 |
| 37 | TCP (OnStar) – Telematics Communication Platform |
| 38 | WCM – Wireless Charger Module |
| 39 | HI VOLTAGE SYS LCKOUT – High Voltage System Lockout |
| 40 | VCU Batt 2 – Virtual Cockpit Unit Battery 2 |
| 41 | ELM 6 – Exterior Lighting Module 6 |
| 42 | - |
Engine compartment fuse box:
| Fuse/Relay N° | Functions |
| 1 | Spare |
| 2 | - |
| 3 | Spare |
| 4 | Spare |
| 5 | Spare |
| 6 |
- MSM – Memory Seat Module
|
| 7 | PEEV/PCEV & ECFV/CHFV – Primary Evaporator Expansion Valve/Primary Chiller Expansion Valve and External Condenser Flow Valve/Condensing Heater Flow Valve |
| 8 |
MCV & PLCM – Main Coolant Valve and Power Line Communication Module -
|
| 9 | - |
| 10 | - |
| 11 | - |
| 12 | - OBCM 2 – On Board Charging Module 2 |
| 13 | ESSCP & PECP – Energy Storage System Coolant Pump and Power Electric Cooling Pump |
| 14 | - |
| 15 | TRLR PRK LAMPS – Trailer Park Lamps - |
| 16 | - |
| 17 | - |
| 18 | - |
| 19 | - |
| 20 | - |
| 21 | CPDM – Charge Port Door Motor |
| 22 | - |
| 23 | ECP_S – Electrification Control Processor |
| 24 | - |
| 25 | - |
| 26 | Spare |
| 27 | - |
| 28 | ETC Mod – Electronic Toll Control Module |
| 29 | - |
| 30 | - |
| 31 | - |
| 32 | Spare |
| 33 | Spare |
| 34 | ELM_BAT 5 – Exterior Lighting Module Battery 5 |
| 35 | ELM BAT 4 – Exterior Lighting Module Battery 4 |
| 36 | - |
| 37 | Rear Wiper |
| 38 | ELM BAT 7 – Exterior Lighting Module Battery 7 |
| 39 | ELM BAT 3 – Exterior Lighting Module Battery 3 |
| 40 | - |
| 41 | DSP LF/DSP RF – Left Front and Right Front Door Switch Panel - |
| 42 | SEAT SW & VKM/RLH – Seat Position Switch and Virtual Key Module/Rain Light Humidity |
| 43 | - ECP_E_BATT1 – Electrification Control Processor Battery 1 |
| 44 | - ACM – Air Conditioning Module |
| 45 | RFR & HFRC – Remote Function Receiver and Handsfree Rear Closure |
| 46 | - PFA – Pedestrian Friendly Alert |
| 47 | PRK EMBLEM – Park Emblem - |
| 48 | PTM – Power Tailgate Module |
| 49 | ECP_E_BATT3 – Electrification Control Processor Battery 3 |
| 50 | PWE L/DSP LR – Left Power Window Electronics/Left Rear Door Switch Panel |
| 51 | - |
| 52 | PWE R/DSP R – Right Power Window Electronics/Right Rear Door Switch Panel |
| 53 | FRT WPR – Front Wiper |
| 54 | - |
| 55 | - |
| 56 | - |
| 57 | EBCM 1 – Electronic Brake Control Module 1 |
| 58 | FRT BLWR MTR – Front Blower Motor |
| 59 | - |
| 60 | Horn |
| 61 | Rear Defog |
| 62 | - |
| 63 | SRC – Sunroof Controller |
| 64 | MSM DR/SAET SW DR – Driver Memory Seat Module/Power Seat Driver |
| 65 | PWR SEAT CODR – Power Seat Co-driver |
| 66 | CFM – Condenser Fan Module |
| 67 | Heated Wiper (De-Ice) |
| 68 | Spare |
| 69 | Spare |
| 70 | RELAY’S COIL |
| 71 | HSM_ROW2_SRC2 – Heated Seat Module Row 2 Source 2 |
| 72 | HSM_SRC1 – Heated Seat Module Source 1 |
| 73 | - |
| 74 | - |
| 75 | Spare |
| 76 | Spare |
| 77 | Spare |
| 78 | TRLR ST/TRN RT & TRLR ST/TRN LT – Trailer Stop Turn Right and Trailer Stop Turn Left |
| 79 | HSM_ROW2_SRC1 – Heated Seat Module Row 2 Source 1 |
| 80 | HSM_SRC2 – Heated Seat Module Source 2 |
| 81 | - |
| 82 | Wash Pump |
| 83 | Rear Wiper |
