Citroën C3 Pluriel 2010 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay N° | Rating | Functions |
| 3 | 5A | Airbags |
| 4 | 10A | Diagnostic socket – Clutch switch – Steering angle sensor |
| 5 | 30A | Rear window – Sun roof |
| 6 | 30A | Screen wash |
| 8 | 20A | Digital clock – Controls at the steering wheel – Radio – Display |
| 9 | 30A | Cigar-lighter – Digital clock – Interior lamps – Vanity mirror |
| 10 | 15A | Alarm |
| 11 | 15A | Ignition switch – Diagnostic socket |
| 12 | 15A | Airbag ECU – Rain and brightness sensor |
| 14 | 15A | Parking assistance – Instrument panel – Air conditioning – Bluetooth® telephone |
| 15 | 30A | Central locking – Deadlocking |
| 17 | 40A | Heated rear screen |
| 18 | SHUNT | CUSTOMER PARK SHUNT |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Water-in-diesel-fuel sensor |
| 2 | 15A | Horn |
| 3 | 10A | Screen wash |
| 4 | 20A | Headlamp wash |
| 5 | 15A | Fuel pump |
| 6 | 10A | Power steering |
| 7 | 10A | Coolant level sensor |
| 8 | 25A | Starter |
| 9 | 10A | ECUs (ABS, ESP) |
| 10 | 30A | Engine control actuators (Ignition coil, Electrovalve, Oxygen sensor, Injection) – Canister purge |
| 11 | 40A | Air blower |
| 12 | 30A | Windscreen wiper |
| 14 | 30A | Air pump (petrol version) – Diesel fuel heater |
