Dodge Viper 2008 Fuse Box Info
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Blower Motor |
| 2 | 40A | Anti-Lock Brakes (ABS) Pump Feed/Starter |
| 3 | 30A | Body Control Module (BCM) - Battery Feed |
| 4 | 20A | Amplifier |
| 5 | 30A | Ignition Switch Run/ Accessory Feed - Windows/Adjustable Pedals |
| 6 | 40A | Body Control Module (BCM) - Battery Feed |
| 7 | 30A | Anti-Lock Brakes (ABS) Module |
| 8 | 30A | Ignition Switch Run/ Accessory Feed |
| 9 | 40A | Headlights |
| 10 | 30A | Ignition Switch Run Feed |
| 11 | 20A | Auto Shutdown Relay (ASD) |
| 12 | 20A | Cigar Lighter |
| 13 | 15A | Hazard Flasher |
| 14 | 20A | Auto Shutdown Relay (ASD) |
| 15 | 20A | Rear Window Defogger (EBL) |
| 16, 17 | 20A | Selectable Power Outlet |
| 18 | 15A | Ignition Off Draw (IOD) |
| 19 | 15A | Horn |
| 20 | 15A | Air Conditioning (A/C) Clutch Relay |
| 21 | 15A | Stop Light Switch |
| 22 | 25A | Fuel Pump/Powertrain Control Module (PCM) |
| 23, 24 | 10A | Airbag |
| 60, 61 | 15A | Ignition Run/Start Relay Feed |
| 62, 63 | 15A | Gauges |
| 64, 65 | 10A | Airbag |
| 66, 67 | 20A | Wiper Switch |
| 68, 69 | 20A | Left HID Headlight |
| 70, 71 | 20A | Right HID Headlight |
