Fiat Qubo 2018 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located on the driver's side under the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 12* | 7.5A | Dipped headlight (passenger side) |
| 13 | 7.5/5*A | Dipped headlight (driver side)/Headlight alignment corrector |
| 31 | 5A | INT/A SCM relay coils |
| 32* | 7.5A | Timed interior lighting |
| 36 | 10A | Radio Bluetooth® system node/Blue&Me™ node/EOBD diagnostic socket/Volumetric alarm ECU/Alarm siren ECU |
| 37 | 5A | Instrument panel node/Stop light control (NO) |
| 38 | 20A | Door/luggage compartment lock actuators* |
| 43 | 15A | Windshield washer/rear window washer bidirectional pump |
| 47 | 20A | Front electric window (driver side)* |
| 48 | 20A | Front electric window (passenger side)* |
| 49 | 5A | Control lights/Parking sensors ECU/Electric wing mirrors/Volumetric alarm ECU |
| 51 | 7.5A | INT Radio node/Bluetooth® system ECU/Blue&Me™ node/Electric wing mirrors movement/Clutch switch/Brake light control (NC) |
| 53 | 5A | Instrument panel node |
| 41 | 7.5A | Door mirror defrosters |
| 45 | - | Spare |
| 46 | - | Spare |
| 90 | - | Spare |
| 91 | - | Spare |
| 92 | - | Spare |
| 93 | - | Spare |
| 94 | 15A | Cigar lighter/Passenger compartment power socket |
| 95 | - | Spare |
| 96 | 15A | Cigar lighter/Passenger compartment power socket |
| 97 | 10A | Front seat heater (driver side) |
| 98 | 10A | Front seat heater (passenger side) |
* Some versions only
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 09 | 15A | Spare (trailer kit) |
| 09 | 10A | Methane system solenoid valves (CNG) |
| 10 | 10A | Horns |
| 14 | 15A | Main beam headlights |
| 15 | 15A | Rear power socket |
| 16 | 7.5A | Dualogic™ transmission control unit and gear selector lever (+ ignition power supply) |
| 19 | 7.5A | Air conditioner compressor |
| 20 | 30A | Heated rear window, mirror defrosters |
| 21 | 15A | Fuel pump |
| 08 | 15A | Fog lights |
| 82 | 30A | Dualogic™ pump power supply (+ battery) |
| 84 | 15A | Dualogic™ transmission control unit (+ battery power supply) |
| 85 | 30A | Cigar lighter/Passenger compartment socket/Heated seats/USB APO |
| 87 | 7.5A | IBS battery charge sensor for Start&Stop system (1.3 Multijet Euro 6 with Start&Stop) |
