Ford Fiesta 2016 Fuse Box Info
Passenger compartment fuse box location:
The fuse panel is located behind the glove box. Open the glove box, press the sides inward and swing the glove box down.
Engine compartment fuse box location:
The power distribution box is located in the engine compartment.
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15 A | Ignition switch |
| 2 | 7.5 A | Auto-dimming interior mirror, Autowipers, Heater relay control |
| 3 | 7.5 A | Instrument cluster |
| 4 | 7.5 A | Passenger airbag deactivation indicator, passenger sensing system |
| 5 | 15 A | On-board diagnostics connector |
| 6 | 10 A | Reversing lamps |
| 7 | 7.5 A | Instrument panel, information and entertainment display |
| 8 | 7.5 A | Moonroof |
| 9 | 20 A | Remote keyless entry, Remote keyless starting |
| 10 | 15 A | Audio unit, SYNC module |
| 11 | 20 A | Windshield wipers |
| 12 | 7.5 A | Climate control |
| 13 | 15 A | Rear window wiper |
| 14 | 20 A | Remote keyless entry, Remote keyless starting |
| 15 | 15 A | Windshield wipers |
| 16 | 5 A | Exterior mirrors, Power windows |
| 17 | 15 A | Heated seats |
| 18 | 10 A | Brake lamp |
| 19 | 7.5 A | Instrument cluster |
| 20 | 10 A | Airbags |
| 21 | 7.5 A | Electronic power assisted steering, Instrument cluster, Ignition, Windshield wipers, Passive anti-theft system |
| 22 | 7.5 A | Transmission control unit, Powertrain control module, Anti-lock brake system, Stability assist |
| 23 | 7.5 A | Transmission control unit |
| 24 | 7.5 A | Audio unit |
| 25 | 7.5 A | Exterior mirrors |
| 26 | 7.5 A | Central locking system |
| 27 | - | Not used |
| 28 | - | Not used |
| 29 | - | Not used |
| 30 | - | Not used |
| 31 | 30 A | Power windows |
| 32 | 20 A | Battery back-up sounder |
| 33 | 20 A | Auxilliary power points |
| 34 | 30 A | Power windows |
| 35 | 20 A | Moonroof |
| 36 | - | Not used |
| Relays | ||
| R1 | - | Ignition relay |
| R2 | - | Not used |
| R3 | - | Not used |
| R4 | - | Driver heated seat |
| R5 | - | Passenger heated seat |
| R6 | - | Remote keyless starting |
| R7 | - | Remote keyless starting |
| R8 | - | Battery back-up sounder |
| R9 | - | Accessory delay |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 |
40 A 60 A |
Anti-lock brake system module Stability assist, Anti-lock brake system module |
| 2 |
40 A 60A |
Engine cooling fan relay High speed engine cooling fan relay5 |
| 3 | 60A | Passenger compartment fuse box |
| 4 | 20 A | Body control module, Door locks |
| 5 | - | Not used |
| 6 | 40 A | Blower motor relay, Blower motor |
| 7 | - | Not used |
| 8 | - | Not used |
| 9 | 7.5 A | Foglamp relay coil, High beam relay coil |
| 10 | 15 A | Body control module, Right-hand side exterior lighting |
| 11 | 15 A | Body control module, Left-hand side exterior lighting |
| 14 | - | Not used |
| 15 | - | Not used |
| 16 | - | Not used |
| 17 | - | Not used |
| 18 | - | Not used |
| 19 | 30 A | Fuel injectors |
| 20 | - | Not used |
| 21 |
7.5 A 10A |
Mass air flow sensor2 Fuel injector driver |
| 22 | 15A | Powertrain control module |
| 23 | 15 A | Camshaft sensor, Heated exhaust gas oxygen sensors |
| 24 |
15 A 20A |
Ignition coil3 Ignition coil2 |
| 25 | 10 A | Variable cam timing 1, Variable cam timing 2, Canister purge valve, R5, R6 and R7 relay coil |
| 26 |
7.5A 15A |
ECSS system4 Active grill shutter, Water pump, Air conditioning1 |
| 27 | - | Not used |
| 28 | - | Not used |
| 29 | - | Not used |
| 30 | - | Not used |
| 31 | - | Not used |
| 32 | 60 A | Passenger compartment fuse box |
| 33 | 60A | Power windows |
| 34 |
40 A 60A |
Transmission control module6 High speed engine cooling fan1 |
| 35 | 40 A | Stability assist/anti-lock brake system valve |
| 36 | 30 A | Starter inhibit relay, Starter motor solenoid |
| 37 | 30 A | Heated rear window, Heated mirrors |
| 38 | 20 A | Body control module, Battery saver |
| 39 | 15A | Body control module, Direction indicators |
| 40 | - | Not used |
| 41 | 10A | Air condition clutch solenoid |
| 42 | 7.5A | Powertrain control module, Transmission control module, Canister vent valve |
| 43 | - | Not used |
| 48 | 10A | Left-hand fog lamp |
| 49 | 10A | Right-hand fog lamp |
| 55 | 10A | Left-hand high beam |
| 56 | 10A | Right-hand high beam |
| Relays | ||
| R12 | - | Powertrain control module relay |
| R13 | - | High beam relay |
| R43 | - | Not used |
| R44 | - | Foglamp relay |
| R45 | - | Air conditioning clutch relay |
| R46 | - | Not used |
| R47 | - | Fuel pump relay |
| R50 | - | High speed cooling fan1 |
| R51 | - | Starter inhibit relay |
| R52 | - | Blower motor relay |
| R53 | - | Not used |
| R54 | - | Reversing lamp |
| R57 | - | Engine cooling fan relay |
Fuses:
1: 1.0L EcoBoost
2: 1.0L and 1.6L EcoBoost
3: 1.6L Sigma
4: 1.6L Flex-fuel
5: 1.6L Ecoboost
6: 6-Speed PowerShift Transmission
Relays:
1: 1.0L and 1.6L EcoBoost
