Ford Escort 2000 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located below the instrument panel in front of the driver’s door.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box (Coupe):
| Fuse/Relay | Rating | Functions |
| DRL | 10A | Daytime Running Lamps |
| HAZARD | 15A | Hazard Flasher |
| ROOM | 10A | Engine Controls, RAP System, Radio, Shift Lock, Courtesy Lamps, Starting System, Warning Chime, Instrument Cluster |
| ENGINE | 15A | Electronic Automatic Transaxle, Ignition System, Constant Control Relay Module (PCM Relay) |
| RADIO | 5A | Power Mirrors, Radio, RAP System |
| DOOR LOCK | 30A | Power Door Locks |
| HORN | 15A | Horn, Shift Lock |
| AIR COND | 15A | A/C-Heater, ABS |
| METER | 10A | Backup Lamps, Engine Coolant Level Switch, Instrument Cluster, Rear Window Defrost, Shift Lock, Warning Chime, Turn Signal Switch |
| WIPER | 20A | Wiper/Washer, Blower Motor Relay |
| STOP | 20A | Stop Lamps, Brake Pressure Switch |
| TAIL | 15A | Exterior Lamps, Instrument Illumination |
| SUN ROOF | 15A | Power Moonroof |
| ASC | 10A | Speed Control |
| P. WINDOW | 30A | Power Windows |
| CIGAR | 20A | Cigar Lighter |
| AIR BAG | 10A | Air Bags |
| FOG | 10A | Fog Lamps, Daytime Running Lamps (DRL) |
| AUDIO | 15A | Premium Sound Amplifier, CD Changer |
| FUEL INJ. | 10A | H02S, Evaporative Emission Purge Flow Sensor |
| BLOWER | 30A | Blower Motor Relay |
Passenger compartment fuse box (Sedan):
| Fuse/Relay | Rating | Functions |
| R.WIPER | 10A | Daytime Running Lamps, Liftgate Wiper/Washer |
| HAZARD | 15A | Hazard Flasher, Engine Controls |
| ROOM | 10A | Remote Anti-Theft Personality (RAP) Module, Radio, Shift Lock, Courtesy Lamps, Starting System, Warning Chime |
| ENGINE | 15A | Air Bag, Engine Controls, TR Sensor |
| MIRROR | 5A | Power Mirrors, Radio, Remote Keyless Entry (RKE) |
| DOOR LOCK | 30A | Power Door Locks |
| HORN | 15A | Horn |
| AIR COND | 15A | A/C-Heater, ABS |
| METER | 10A | Backup Lamps, Engine Controls, Instrument Cluster, Rear Window Defrost, Shift Lock, Warning Chime, Turn Signal Switch |
| WIPER | 20A | Wiper/Washer, Blower Relay |
| STOP | 15A | Stop Lamps |
| TAIL | 15A | Exterior Lamps, Instrument Illumination |
| SUN ROOF | 15A | Power Moonroof |
| ASC | 10A | Speed Control |
| CIGAR | 20A | Cigar Lighter |
| AIR BAG | 10A | Joint Connector, Air Bag Diagnostic Monitor |
| FOG | 10A | Fog Lamps, Daytime Running Lamps (DRL) |
| AUDIO | 15A | Radio |
| FUEL INJECTOR |
10A | H02S, Evaporative Emission Purge Flow Sensor |
| P. WINDOW | 30A | Power Windows |
| BLOWER | 30A | A/C-Heater |
Engine compartment fuse box (Coupe):
| Fuse/Relay | Rating | Functions |
| FUEL INJ. | 30A | Air Bags, Constant Control Relay Module (PCM Relay), Generator |
| DEFOG | 30A | Rear Window Defrost |
| MAIN | 100A | Overall Circuit Protection |
| BTN | 40A | Hazard, Stop, Door Lock, Tail, Room and Horn Fuses of the I/P Fuse Panel |
| ABS | 60A | ABS Main Relay |
| COOLING FAN | 40A | Constant Control Relay Module (Cooling Fan) |
| OBD-II | 10A | Data Link Connector (DLC), Instrument Cluster |
| FUEL PUMP | 20A | Constant Control Relay Module (Fuel Pump) |
| HEAD RH | 10A | Headlamps |
| HEAD LH | 10A | Headlamps |
Engine compartment fuse box (Sedan):
| Fuse/Relay | Rating | Functions |
| FUEL INJ. | 30A | Air Bags, Engine Controls, Generator |
| DEFOG | 30A | Rear Window Defrost |
| MAIN | 100A | Charging System, BTN, Cooling Fan, Fuel Pump, OBD-II, ABS Fuses, Ignition Switch, Headlamps |
| BTN | 40A | Hazard |
| ABS | 60A | ABS Main Relay |
| COOLING FAN | 40A | Constant Control Relay Module |
| OBD-II | 10A | Data Link Connector (DLC), Instrument Cluster |
| FUEL PUMP | 30A | Engine Controls |
| HEAD RH | 10A | Headlamps |
| HEAD LH | 10A | Headlamps |
