Ford F-150 Lightning 2025 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is in the right-hand side of the passenger footwell behind a trim panel.
Under hood compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not used |
| 2 | 10A | Driver window switch - delayed accessory feed, Moonroof, Sliding backglass switch |
| 3 | 7.5A | Wireless accessory charging module |
| 4 | 20A | Not used (spare) |
| 5 | - | Not used |
| 6 | 10A | Driver window switch - powered at all times |
| 7 | 10A | Gearshift module |
| 8 | 5A | Telematics control module, Power tailgate control module |
| 9 | 5A | Inclination sensor |
| 10 | - | Not used |
| 11 | - | Not used |
| 12 | 7.5A | Climate control module |
| 13 | 7.5A | Instrument cluster, Steering column control module |
| 14 | 15A | Frunk module |
| 15 | 15A | Integrated control module, Accessory protocol interface module |
| 16 | - | Not used |
| 17 | 7.5A | Not used (spare) |
| 18 | 7.5A | Not used (spare) |
| 19 | 5A | Headlamp switch, Bluetooth low energy module |
| 20 | 5A | Start switch |
| 21 | 5A | Trailer brake switch |
| 22 | 5A | Not used (spare) |
| 23 | 30A | Driver door control module |
| 24 | 30A | Moonroof, Sunshade module |
| 25 | 20A | Not used (spare) |
| 26 | 30A | Passenger door control module |
| 27 | 30A | Not used (spare) |
| 28 | 30A | Amplifier |
| 29 | 15A | Adjustable pedal switch, 12" display, 15" display |
| 30 | 5A | Not used (spare) |
| 31 | 10A | Driver status monitor, Radio transceiver module |
| 32 | 20A | Radio, Enhanced central gateway |
| 33 | - | Not used |
| 34 | 30A | Run/start relay |
| 35 | 5A | Instrument panel switch pack, 15" display |
| 36 | 15A | Rear heated seat module, Steering column control module, Auto-dimming mirror |
| 37 | 20A | Not used (spare) |
| 38 | 30A | Rear window switches |
Under hood compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 40A | Body control module |
| 3 | 40A | Body control module |
| 5 | 5A | Primary drive control module, Secondary drive control module |
| 6 | 25A | Powertrain control module |
| 7 | 20A | Powertrain control module heater cooling pump |
| 8 | 20A | A/C control module, Active grille shutter, Front bumper valance motor, Electric fan relay coil |
| 10 | 10A | Powertrain control module |
| 13 | 40A | Blower motor |
| 15 | 25A | Horn |
| 17 | 5A | Charge port status indicator |
| 21 | 10A | Not used (spare) |
| 22 | 10A | Electronic power assist steering module |
| 23 | 10A | Anti-lock brake system module |
| 24 | 10A | Primary drive control module, Secondary drive control module, Powertrain control module |
| 25 | 10A | Trailer camera module, Trailer tire pressure monitoring system, Trailer sway control |
| 27 | 25A | Primary drive control module fluid pump |
| 28 | 50A | Anti-lock brake system module |
| 29 | 50A | Anti-lock brake system module |
| 30 | 40A | Driver seat module |
| 31 | 30A | Passenger power seat |
| 32 | 20A | Power point |
| 33 | 20A | Not used (spare) |
| 34 | 20A | Auxiliary power point |
| 37 | 30A | Power tailgate module |
| 38 | 40A | Climate control module |
| 41 | 25A | Heated rear window |
| 42 | 30A | Trailer brake control module |
| 46 | 10A | Battery charger control module |
| 48 | 20A | Rear heated seat module |
| 50 | 40A | Heated backlight |
| 55 | 30A | Trailer tow park lamps |
| 56 | 20A | Trailer tow stoplamps |
| 58 | 10A | Trailer tow backup lamps |
| 67 | 25A | Secondary drive control module fluid pump |
| 69 | 30A | Front wiper motor |
| 72 | 40A | Front trunk module |
| 91 | 20A | Trailer tow lighting module |
| 95 | 15A | Primary drive control module |
| 96 | 20A | Coolant pump |
| 97 | 10A | A/C pressure and temperature sensor, High voltage battery cooling module |
| 99 | 15A | Secondary drive control module, High voltage positive temperature coefficient heater |
| 100 | 25A | Left-hand headlamp |
| 101 | 25A | Right-hand headlamp |
| 107 | 30A | Trailer tow lighting module |
| 116 | 10A | Second battery charger control module |
| 124 | 5A | Rain sensor |
| 125 | 10A | USB smart charger 1, USB smart charger 2 |
| 134 | 25A | Driver multi-contour seat, Passenger multi-contour seat |
| 137 | 20A | Advanced driver assistance system module, High mounted stoplamp rear video camera |
| 138 | 10A | Tailgate release solenoid |
| 139 | 5A | USB smart charger 3 |
| 146 | 15A | Battery energy control module |
| 159 | 5A | Direct current/direct current converter |
| 160 | 10A | Smart datalink connector |
| 168 | 15A | Battery energy control module, Pedestrian sounder |
| 169 | 20A | Coolant pump |
| 170 | 20A | High voltage battery coolant pump |
| 181 | 5A | Headlamp control module |
| 190 | 5A | Not used (spare) |
| 202 | 60A | Body control module |
| 210 | 30A | Body control module |
Battery fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 3A | Battery monitoring system |
