Ford EcoSport 2018 Fuse Box Info
Fuse box location:
The fuse box is located behind the glove box.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | Not used |
| 2 | 5A | Humidity and incar temperature sensor |
| 3 | 10A | Reverse parking aid module |
| 4 | 10A | Ignition switch, Key in switch & solenoid, Start-Stop switch |
| 5 | 20A | Central lock relay, Central unlock relay internal |
| 6 | 10A | Power windows switches, Power sunroof switch & module inverter |
| 7 | 30A | Not used |
| 8 | 5A | Not used |
| 9 | 5A | Electrochromic inside mirror, Overdrive off switch, Passenger Airbag detection ON / OFF |
| 10 | 10A | Smart data link connector |
| 11 | 5A | Telematic control unit (embedded modem) |
| 12 | - | Not used |
| 13 | 15A | Driver unlock relay |
| 14 | 30A | Not used |
| 15 | 15A | Extended power module relay starter |
| 16 | 15A | Not used |
| 17 | 15A | SYNC, Mini electronic finish panel |
| 18 | 7.5A | Not used |
| 19 | 7.5A | Not used |
| 20 | 10A | Security Horn |
| 21 | 7.5A | Climate Control Head |
| 22 | 7.5A | Steering column control module, Smart data link logic, Instrument cluster |
| 23 | 20A | Audio control module |
| 24 | 20A | Extended power mode module |
| 25 | 30A | Not used |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 60A | Engine cooling fan relay 2 |
| 2 | 50A | Engine cooling fan relay 1 |
| 3 | 40A | DC / AC inverter |
| 4 | 40A | ABS with Eletronic Stability Program (valves) |
| 5 | 30A | Driver power seat |
| 6 | 40A | Front blower motor |
| 7 | 10A | Brake on/off Switch |
| 8 | 20A | Moonroof |
| 9 | 15A | Rear washer, Wiper |
| 10 | 7.5A | A/C clutch relay |
| 11 | 5A | Power point coil, Horn, Fuel pump |
| 12 | - | Powertrain control module relay |
| 13 | - | Starter relay |
| 14 | 10A | Heated exterior mirrors |
| 15 | 5A | Rain sensor, Rear washer |
| 16 | 10A | Rear window wiper motor |
| 17 | 20A | Power point 1 (or cigar lighter) |
| 18 | 20A | Power point 2 |
| 19 | - | Not used |
| 20 | 20A | Powertrain control module |
| 21 | 15A | Oxygen sensor heater, Catalyst monitor sensor, Canister purge valve, Variable camshaft timing solenoid valves, Vapor blocking valve |
| 22 | 10A | A/C clutch control, Fan control - on/off, Puller fan coil (1.0 L), Coolant pump control, Run / on water pump, Exhaust gas recirculation baypass solenoid, Variable oil pump control, Variable A/C compressor valve, All-wheel drive relay module (2.0 L), Active grille shutter |
| 23 |
15A 20A |
For ignition coils (2.0 L) For ignition coils (1.0 L) |
| 24 | - | Not used |
| 25 | 15A | Subwoofer amplifier |
| 26 | 20A | Provision for trailer tow wiring |
| 27 | - | Not used |
| 28 | 10A | Left horn |
| 29 | 10A | Right horn |
| 30 | 15A | Heated Steering wheel |
| 31 | 5A | Temperature mass air flow sensor (2.0L) |
| 32 | 30A | Body control module (battery voltage) |
| 33 | 60A | ABS/eletronic stability program pump |
| 34 | 50A | Trailer tow module |
| 35 | 40A | Heated backlite |
| 36 | 30A | Starter |
| 37 | 40A | Positive temperature coefficient heater |
| 38 | - | Not used |
| 39 | - | Not used |
| 40 | 25A | Heated seats (climate control module) |
| 41 | 15A | Subwoofer amplifier |
| 42 | 7.5A | Intercooler puller fan (1.0 L) |
| 43 | - | Auxiliary power point relay |
| 44 | - | Windshield wiper relay |
| 45 | - | Front blower motor relay |
| 46 | 30A | Power window switch power switch times |
| 47 | 20A | Fuel pump |
| 48 | - | Not used |
| 49 | 20A | Assisted direct start transmission fluid pump (stop/start) - power |
| 50 | - | Run/start relay |
| 51 | - | Not used |
| 52 | - | Vehicle horn relay |
| 53 | - | Not used |
| 54 | - | Rear washer relay |
| 55 | - | Not used |
| 56 | 5A | Electrical power assisted system module, Powertrain control module |
| 57 | 10A | Start / Stop - transmission fluid pump |
| 58 | 10A | Left hand blind spot monitor module, Right hand blind spot monitor module, Rear video camera |
| 59 | 5A | ABS module |
| 60 | 5A | Heated backlite, Heated windshield left (to heated wiper park) |
| 61 | - | Heated backlite / heated mirror relay |
| 62 | - | Engine cooling fan 2 relay |
| 63 | 25A | Front wiper |
| 64 | 30A | Body control module - run/start bus |
| 65 | - | Fuel pump relay |
| 66 | - | Not used |
| 67 | - | A/C clutch relay |
| 68 | - | Engine cooling fan 1 relay |
| 69 | - | Not used |
| 70 | - | Not used |
| 71 | - | Not used |
| 72 | - | Not used |
| 73 | - | Heated wiper park relay |
| 74 | 10A | Heated wiper park |
| 75 | - | Not used |
| 76 | - | Positive temperature coefficient heater relay |
| 77 | - | Puller fan (1.0 L Fox) relay |
| 78 | - | Not used |
| 79 | - | Positive temperature coefficient heater relay |
Battery Fuse Box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 250A | Engine compartment fuse box |
| 2 | 60A | Electric power assist steering |
| 3 | 100A | Body control module |
| 4 | 70A | Heating control unit |
| 5 | 275A | Starter |
