Honda CR-V 2001 Fuse Box Info
Passenger compartment fuse box location:
The interior fuse box is underneath the dashboard on the driver's side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Not Used |
| 2 | - | Not Used |
| 3 | 10A | Rear Wiper, Washer |
| 4 | 10A | Right Headlight High Beam |
| 5 | 10A | Left Headlight High Beam |
| 6 | 10A | Rear Accessory Power Socket |
| 7 | 20A | Power Window Rear Left |
| 8 | 20A | Power Window Rear Right |
| 9 | 15A | IGN Coil |
| 10 | 20A | Power Window Front Assistant |
| 11 | 20A | Power Window Front Driver |
| 12 | 7.5A | Turn Lights |
| 13 | 15A | Fuel Pump (SRS Unit) |
| 14 | 7.5A | Cruise Control |
| 15 | 7.5A | ACG (IG), SP Sensor |
| 16 | 7.5A | ABS |
| 17 | 7.5A | Heater A/C Relay |
| 18 | 7.5A | Running Light Relay* |
| 19 | 7.5A | Back-up Light |
| 20 | 7.5A | Running Light* |
| 21 | 10A | Right Headlight Low Beam |
| 22 | 10A | Left Headlight Low Beam |
| 23 | 10A | SRS |
| 24 | 7.5A | Power Window Relay |
| 25 | 7.5A | Meter |
| 26 | 20A | Front Wiper, Front Washer |
| 27 | 10A | Front Accessory Power Socket |
| 28 | 10A | Radio |
| 29 | - | Not used |
| 30 | 7.5A | Meter Light |
| 31 | 7.5A | Starter Signal |
| 32 | 7.5A | License Light, Taillight |
| 33 | 7.5A | Inter Lock Unit |
| 34 | 7.5A | Spare Fuse |
| 35 | 10A | Spare Fuse |
| 36 | 15A | Spare Fuse |
| 37 | 20A | Spare Fuse |
| 38 | - | Not Used |
* On Canadian models
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 100A | Main Fuse Battery |
| 2 | 40A | Main Fuse Ignition Starter |
| 3 | 20A | Rear Defogger |
| 4 | 40A | Power Window |
| 5 | 40A | Option |
| 6 | 30A | Headlight |
| 7 | 40A | Healer Motor |
| 8 | 10A | Hazard |
| 9 | 15A | Horn, Stop Light |
| 10 | 20A | Door Lock Unit |
| 11 | 20A | Cooling Fan |
| 12 | 20A | Condenser Fan |
| 13 | 15A | FI E/M (ECM/PCM) |
| 14 | 7.5A | Back-up (Radio) |
| 15 | 7.5A | Interior Light |
ABS Fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 7.5A | Motor Check |
| 2 | 20A | ABS + B |
| 3 | 40A | ABS Pump Motor |
