Kia Rondo 2013 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay Name | Rating | Functions |
| AUDIO | 15A | Audio |
| MEMORY | 15A | BCM, Digital clock, Mirror folding relay, Instrument cluster, Room lamp, Sunvisor lamp, Door warning switch, A/C control module |
| MIRR HTD | 10A | Outside mirror motor & Defogger, A/C control module |
| A/BAG | 15A | SRS control module |
| D/CLOCK | 10A | Power outside mirror switch, Audio, BCM, Digital clock, ATM key lock control module |
| W/DEICER | 15A | Windshield defogger relay |
| CLUSTER | 10A | Instrument cluster, Pre-excitation resistor |
| TELL TALE | 10A | Digital clock |
| C/LIGHTER | 15A | Cigarette lighter |
| A/BAG IND | 10A | Instrument cluster |
| MODULE-1 | 10A | ATM key lock control module, Steering angle sensor, Cluster, Back warning buzzer, ESC switch, BCM, Auto light control module |
| P/OUTLET FR | 20A | Front power outlet |
| SPARE | 15A | Spare fuse |
| T/SIG | 10A | Hazard switch |
| RR WIPER | 15A | Rear wiper motor, Rear wiper relay, Multifunction switch |
| H/LP | 10A | Head lamp relay |
| SPARE | 10A | Spare fuse |
| A/CON | 10A | A/C control module, Blower relay |
| FRT WIPER | 25A | Wiper relay, Wiper motor, Multifunction switch |
| MODULE-2 | 10A | Sunroof, Rain sensor, Seat warmer relay, BCM |
| SPARE | 15A | Spare fuse |
| TAIL-RH | 10A | Head lamp RH, Rear combination lamp RH, License lamp, DRL control module, Instrument panel illumination |
| T/GATE OPEN | 15A | Fuel filler door switch, Tailgate relay |
| STOP LP | 15A | Stop lamp switch |
| TAIL-LH | 10A | Head lamp LH, Rear combination lamp LH, Front fog lamp relay |
| FRT FOG | 15A | Front fog lamp relay |
| START | 10A | Burglar alarm relay, Start relay coil, Inhibitor switch |
| DR/LOCK | 25A | Door lock/unlock relay |
| HAZARD | 15A | Hazard switch, Hazard relay |
| TPMS | 15A | Tire pressure monitoring system (if equipped) |
| P/WDW-LH | 25A | Power window main switch, Power window switch LH |
| ATM LOCK | 10A | Sports mode switch, Data link connector, A/C control module, Multipurpose check connector, Occupant classification system |
| P/WDW-RH | 25A | Power window main switch, Power window switch RH |
| SPARE | 30A | Spare fuse |
| SAFETY PWR | 25A | Safety window motor (if equipped) |
| P/SEAT-LH | 30A | Driver power seat control switch |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| I/P B+ 2 | 40A | I/P junction box |
| HORN RELAY | - | Horn relay |
| H/LP LOW RELAY | - | Head lamp (Low) relay |
| H/LP HI RELAY | - | Head lamp (High) relay |
| ABS 2 | 40A | ABS/ESC control module |
| DRL | 15A | DRL control module |
| HORN | 15A | Horn relay, Burglar horn relay |
| H/LP LOW | 15A | Head lamp relay (Low) |
| F/PUMP | 20A | Fuel pump relay |
| H/LP HI | 15A | Head lamp relay (High) |
| ECU | 15A | TCM, Generator, ECM |
| ALTERNATOR |
125A (2.4L) 150A (2.7L) |
Generator |
| RAD FAN HI RELAY | - | Radiator fan (High) relay |
| RAD FAN LOW RELAY | - | Radiator fan (Low) relay |
| F/PUMP RELAY | - | Fuel pump relay |
| ABS 1 | 40A | ABS/ESC control module |
| SPARE | 15A | Spare fuse |
| MAIN | 30A | Engine control relay |
| SPARE | 10A | Spare fuse |
| SPARE | 15A | Spare fuse |
| SPARE | 20A | Spare fuse |
| P/AMP | 25A | Amplifier |
| SPARE | 15A | Spare fuse |
| S/ROOF | 20A | Sunroof control module |
| SPARE | 20A | Spare fuse |
| RAD FAN | 40A | Radiator fan relay |
| PCU | 10A | Pulse generator, ECM, Radiator fan relay, Stop lamp switch |
| ABS | 10A | ABS/ESC control module, Multipurpose check connector |
| S/WARMER | 20A | Seat warmer relay |
| ATM | 20A | ATM control relay |
| TAIL | 20A | Tail lamp relay |
| SPARE | 20A | Spare fuse |
| BACK-UP | 10A | Vehicle speed sensor, Back-up lamp switch, Transaxle range switch |
| WIPER RELAY | - | Wiper relay |
| MAIN RELAY | - | Main relay |
| RR HTD | 40A | Rear defogger relay |
| IGN 1 | 40A | Ignition switch (ACC, IG1) |
| I/P B+ 1 | 30A | I/P junction box |
| ACC SOCKET | 20A | Rear power outlet |
| A/CON | 10A | A/C relay |
| START RELAY | - | Start relay |
| ECU-1 | 20A | ECM |
| IGN COIL | 20A | Ignition coil |
| SNSR 3 | 15A | A/C relay, Injector, Lambda sensor, Radiator fan relay, Stop switch (Brake test line) |
| BLOWER | 40A | Blower relay |
| ATM CONT RELAY | - | ATM control relay |
| IGN 2 | 30A | Ignition switch (IG2, START), Start relay |
| A/CON RELAY | - | A/C relay |
| SNSR 2 | 15A | Fuel pump relay, Oxygen sensor |
| SNSR 1 | 15A | Immobilizer control module, Camshaft position sensor, Mass air flow sensor, Oil control valve, Canister purge solenoid valve |
