Seat Altea 2006 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located under the instrument panel behind the cover on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | Vacant |
| 2 | - | Vacant |
| 3 | - | Vacant |
| 4 | - | Vacant |
| 5 | - | Vacant |
| 6 | - | Vacant |
| 7 | - | Vacant |
| 8 | - | Vacant |
| 9 | 5A | Airbag |
| 10 | - | Vacant |
| 11 | - | Vacant |
| 11 | 5A | After-sales kit |
| 12 | 10A | Left hand side xenon headlight |
| 13 | 5A | Heating controls/ESP, ASR switch/Reverse gear/Telephone pre-installation |
| 14 | 10A | ABS/ESP control unit/ Engine/ Headlights/ Trailer control unit/ light switch/ Instrument panel |
| 15 | 10A | Headlight control unit/ Heated windscreens/ Instrument lighting/ Diagnosis control unit |
| 16 | 10A | Right hand side xenon headlight |
| 17 | 10A | D2L Engine (2.0 litre 147 kW 4 speed TFSI) |
| 18 | - | Vacant |
| 19 | - | Vacant |
| 20 | 10A | Park Pilot (Parking aid) / Gear selector lever/ ESP control unit |
| 21 | 7.5A | Cable control unit |
| 22 | 5A | Volumetric alarm sensor/alarm siren |
| 23 | 10A | Diagnosis/Rain sensor/Light switch |
| 24 | - | Vacant |
| 25 | 20A | Automatic gearbox control unit connection |
| 26 | 20A | Vacuum pump |
| 27 | - | Vacant |
| 28 | 20A | Windscreen wiper motor/Cable control unit |
| 29 | - | Vacant |
| 30 | 20A | Cigarette lighter / socket |
| 31 | - | Vacant |
| 32 | - | Vacant |
| 33 | 40A | Heater |
| 34 | - | Vacant |
| 35 | - | Vacant |
| 36 | 10A | 2.0 litre 147 kW engine |
| 37 | 10A | 2.0 litre 147 kW engine |
| 38 | 10A | 2.0 litre 147 kW engine |
| 39 | 15A | Trailer control unit (coupling) |
| 40 | 20A | Trailer control unit (indicators, brakes and left side) |
| 41 | 20A | Trailer control unit (fog light, reversing light and right side) |
| 42 | 15A | Towing kit |
| 43 | - | Vacant |
| 44 | 25A | Rear window heater |
| 45 | 30A | Front electric windows |
| 46 | 30A | Rear electric windows |
| 47 | 15A | Engine (gauge, fuel relay) |
| 48 | 20A | Convenience controls |
| 49 | 40A | Heating controls |
| 50 | 30A | Heated seats |
| 51 | 20A | Sunroof |
| 52 | 20A | Headlight washer system |
| 53 | 20A | Towing kit |
| 54 | 5A | Taxi (taxi metre power supply) |
| 55 | 20A | Towing kit |
| 56 | 15A | Taxi (transmitter power supply) |
| 57 | - | Vacant |
| 58 | 30A | Central locking control unit |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Left part | ||
| 1 | 30A | Windscreen wipers |
| 2 | 5A | Steering column |
| 3 | 5A | Cable control unit |
| 4 | 10A | ABS |
| 5 | 15A | AQ gearbox |
| 6 | 5A | Instrument panel |
| 7 | - | Vacant |
| 8 | 15A | Radio |
| 9 | 5A | Telephone |
| 10 |
5A 10A |
Main relay in the FSI / diesel engine compartment / injection module supply Main relay in the engine compartment D2L (2.0 FSI 147 kW) |
| 11 | - | Vacant |
| 12 | 5A | Gateway |
| 13 |
25A 30A |
Petrol injection module supply Diesel injection module supply |
| 14 | 20A | Coil |
| 15 |
5A 10A |
Engine T71 / 20 FSI Pump relay |
| 16 | 30A | ADS pump |
| 17 | 15A | Horn |
| 18 | - | Vacant |
| 19 | 30A | Clean |
| 20 | - | Vacant |
| 21 | 15A | Lambda probe |
| 22 | 5A | Brake pedal, speed sensor |
| 23 |
5A 10A 15A |
Engine 1.6, main relay (relay n° 100) T 71 diesel EGR 2.0 D2L High-pressure fuel pump |
| 24 | 10A | ARF, change valve |
| 25 | 40A | Right lighting |
| 26 | 40A | Left lighting |
| 27 |
40A 50A |
1.6 SLP engine 1.9 TDI Glow plug relay |
| 28 | 40A | KL15 |
| 29 |
50A 30A |
Electric windows (front and back) Electric windows (front) |
| 30 | 40A | X - relief relay |
| Side box | ||
| B1 |
150A 200A |
Alternator < 140 W Alternator > 140 W |
| C1 | 80A | Power steering |
| D1 | 100A | Multi-terminal voltage supply “30”. Internal fuse box |
| E1 | 80/50A | Ventilator > 500 W / Ventilator < 500 W |
| F1 | 100A | PTCs (Supplementary electrical heating using air) |
| G1 | 50A | Trailer fuse voltage supply in internal fuse box |
| H1 | - | Central locking control unit (4F8 with autolock) |
