Toyota Highlander 2011 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located under the instrument panel on the driver’s side.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° and Name | Rating | Functions |
| 1. P/SEAT | 30A | Power seat |
| 2. POWER | 30A | Power windows |
| 3. RR DOOR RH | 25A | Power windows |
| 4. RR DOOR LH | 25A | Power windows |
| 5. FR FOG | 15A | Front fog lights |
| 6. OBD | 7.5A | On-board diagnosis system |
| 7. A/C W/PMP | 7.5A | No circuit |
| 8. STOP | 10A | Enhanced vehicle stability control system, multiplex communication system, multiport fuel injection system/sequential multiport fuel injection system, shift lock system, stop lights |
| 9. DOOR NO.2 | 25A | Power windows |
| 10. AM1 | 7.5A | Starting system |
| 11. P/SEAT (PS) | 30A | Power seat |
| 12. A/C NO.1 | 10A | Air conditioning system |
| 13. FUEL OPN | 7.5A | No circuit |
| 14. S/ROOF | 30A | Electric moon roof |
| 15. TAIL | 15A | Parking lights, tail lights, license plate lights, fog lights, trailer lights |
| 16. PANEL | 7.5A | Glove box light, instrument panel lights, switch illumination |
| 17. ECU IG NO.1 | 10A | Multiplex communication system, electric moon roof, electronically controlled automatic transmission system, power back door, seat heaters, tire pressure warning system, electronic power steering, anti-glare inside rear view mirror, shift lock system, tire pressure warning system |
| 18. ECU IG NO.2 | 7.5A | Enhanced vehicle stability control system |
| 19. A/C NO.2 | 10A | Air conditioning system |
| 20. WASH | 20A | Windshield wipers and washer |
| 21. S-HTR | 20A | Seat heaters |
| 22. GAUGE NO.1 | 10A | Audio system, back-up lights, charging system, emergency flashers, traction control system, windshield wiper de-icer, air conditioning system, charging system, rear view monitor system, trailer lights, multiport fuel injection system/sequential multiport fuel injection system |
| 23. FR WIP | 30A | Windshield wipers and washer |
| 24. RR WIP | 15A | Rear window wiper and washer |
| 25. IGN | 10A | Multiport fuel injection system/ sequential multiport fuel injection system, steering lock system, smart key system, SRS airbag system |
| 26. GAUGE NO.2 | 7.5A | Gauges and meters, rear view monitor system |
| 27. ECU-ACC | 7.5A | Outside rear view mirrors, shift lock system, smart key system, multiplex communication system |
| 28. ACC SOCK NO.1 | 10A | Power outlet |
| 29. ACC SOCK NO.2 | 20A | Power outlet |
| 30. RADIO NO.2 | 7.5A | Audio system, clock, rear seat entertainment system, interior lights, personal lights |
Engine compartment fuse box (Fuse box 1):
| Fuse/Relay N° and Name | Rating | Functions |
| 1. SPARE | 7.5A | Spare fuse |
| 2. SPARE | 15A | Spare fuse |
| 3. SPARE | 25A | Spare fuse |
| 4. DEF RLY | 10A | Rear window defogger |
| 5. MIR HTR | 20A | Outside rear view mirror defoggers |
| 6. PWR OUTLET | 20A | Power outlet |
| 7. DOOR NO.1 | 25A | Multiplex communication system |
| 8. EFI NO.2 | 10A | Multiport fuel injection system/ sequential multiport fuel injection system |
| 9. EFI NO.3 | 10A | Multiport fuel injection system/ sequential multiport fuel injection system |
| 10. INJ NO.1 | 15A | Starting system |
| 11. INJ NO.2 | 10A | Multiport fuel injection system/ sequential multiport fuel injection system |
| 12. HTR | 50A | Air conditioning system |
| 13. VSC NO.1 | 50A | Enhanced vehicle stability control system |
| 14. FAN MAIN | 50A | Electric cooling fan |
| 15. VSC NO.2 | 30A | Enhanced vehicle stability control system |
| 16. PTC NO.1 | 50A | Air conditioning system |
| 17. PTC NO.2 | 30A | Air conditioning system |
| 18. PTC NO.3 | 30A | Air conditioning system |
| 19. RR CLR | 40A | Air conditioning system |
| 20. RR DEF | 30A | Rear window defogger |
| 21. PBD | 30A | Power back door |
| 22. ALT | 140A | MIR HTR, PWR OUTLET, DOOR NO.1, HTR, RR DEF, FAN MAIN, VSC NO.1, PTC NO.1, RR CLR, PTC NO.2, PTC NO.3, VSC NO.2, PBD |
| 23. EPS | 80A | Electric power steering |
| 24. ST | 30A | Starting system |
| 25. CRT | 10A | Rear seat entertainment system, audio system |
| 26. RADIO NO.1 | 15A | Audio system |
| 27. ECU-B NO.1 | 10A | Steering sensor, gauges and meters, clock, main body ECU, wireless remote control, smart key system, power back door, multiinformation display, front passenger occupant classification system |
| 28. DOME | 10A | Vanity lights, personal lights, interior light, gauges and meters, engine switch light, door courtesy lights |
| 29. TOWING | 30A | Trailer lights |
| 30. STR LOCK | 20A | Steering lock system |
| 31. EFI MAIN | 25A | Multiport fuel injection system/ sequential multiport fuel injection system, EFI NO.2, EFI NO.3 |
| 32. HAZ | 15A | Turn signal lights |
| 33. IG2 | 25A | INJ NO.1, INJ NO.2, IGN, GAUGE NO.2 |
| 34. AMP | 15A | Audio system |
| 35. RR FOG | 7.5A | No circuit |
| 36. DEICER | 15A | Windshield wiper de-icer |
| 37. G/H | 10A | Glass hatch, multiplex communication system, outer foot lights |
| 38. ALT-S | 7.5A | Charging system |
| 39. AM2 | 7.5A | Multiplex communication system |
| 40. H-LP LH HI | 15A | Left-hand headlight (high beam) |
| 41. H-LP RH HI | 15A | Right-hand headlight (high beam) |
| 42. H-LP LH LO | 15A | Left-hand headlight (low beam) |
| 43. H-LP RH LO | 15A | Right-hand headlight (low beam) |
| 44. HORN | 10A | Horn |
| 45. EFI NO.1 | 10A | Multiport fuel injection system/ sequential multiport fuel injection system, smart key system |
| 46. ETCS | 10A | Multiport fuel injection system/ sequential multiport fuel injection system |
| 47. A/F | 20A | Air fuel ratio sensor |
| 48. S-HORN | 7.5A | Horn |
Engine compartment fuse box (Fuse box 2):
| Fuse/Relay N° and Name | Rating | Functions |
| 1. INV-W/P | 15A | No circuit |
| 2. IGCT NO.2 | 7.5A | No circuit |
| 3. A/C | 10A | No circuit |
