Yamaha VMAX 1700 2014 Fuse Box Info
Fuse box location:
Fuse Box Diagram | Layout
Fuse box A:
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | ABS solenoid fuse |
| 2 | 15A | Fuel injection system fuse |
| 3 | - | Spare fuse |
Fuse box B:
| Fuse/Relay N° | Rating | Functions |
| 1 | 20A | Ignition fuse |
| 2 | 7.5A | ABS control unit fuse |
| 3 | 15A | Headlight fuse |
| 4 | 7.5A | Backup fuse (for clock) |
| 5 | 7.5A | Electronic throttle valve fuse |
| 6 | 20A | Radiator fan fuse |
| 7 | - | Spare fuse |
| 8 | 15A | Signaling system fuse |
| 9 | 7.5A | Sub radiator fan fuse |
Main fuse (50A), ABS motor fuse (30A) and ABS motor spare fuse are located near battery.
