Yamaha Road Star Silverado 2005 Fuse Box Info
Fuse box location:
The fuse box is located behind panel A, on the left side.
Fuse Box Diagram | Layout
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | Signaling system fuse |
| 2 | 15A | Ignition fuse |
| 3 | Headlight fuse: | |
| 15A | XV17A | |
| 15A | XV17AW | |
| 20A | XV17AM | |
| 20A | XV17AT | |
| 20A | XV17ATM | |
| 4 | 10A | Carburetor heater fuse |
| 5 | Backup fuse (for odometer and clock): | |
| 5A | XV17A | |
| 5A | XV17AW | |
| 10A | XV17AM | |
| 10A | XV17AT | |
| 10A | XV17ATM | |
| 6 | - | Spare fuse |
The main fuse (30A) and spare main fuse are located near to the fuse box.
