Jaguar XJ 2016 Fuse Box Info
Passenger compartment fuse box location:
Engine compartment fuse box location:
Luggage compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 5A | RF-RX, IMS, Tire Pressure Monitoring System (TPMS) |
| 2 | - | - |
| 3 | - | - |
| 4 | 5A | CAN Gateway module |
| 5 | 5A | Dynamic Stability Control (DSC) module, Yaw rate, Steering angle sensor |
| 6 | 5A | Fuse box engine compartment |
| 7 | 20A | Rear climate control |
| 8 | 30A | Front passenger's seat adjustment |
| 9 | 5A | Electric Parking Brake (EPB) |
| 10 | 5A | Air suspension control module |
| 11 | - | - |
| 12 | - | - |
| 13 | - | - |
| 14 | 5A | Brake pedal switch |
| 15 | 30A | Heated rear glass |
| 16 | - | - |
| 17 | 5A | Keyless vehicle module supply |
| 18 | - | - |
| 19 | 5A | Engine control module |
| 20 | 10A | Heated steering wheel |
| 21 | 5A | Air conditioning sensor, Front overhead console, Front dual climate control module and smog sensor |
| 22 | 5A | Transmission control module, E-Diff, Jaguar Drive selector |
| 23 | 5A | Headlamp levelling |
| 24 | 5A | Right-side front and rear lamp clusters |
| 25 | 10A | Left-side front and rear lamp clusters |
| 26 | - | - |
| 27 | - | - |
| 28 | 20A | Rear seat dual climate control module |
| 29 | 20A | Front seat dual climate control module |
| 30 | 25A | Passenger door module |
| 31 | 5A | Rain/light sensor |
| 32 | 25A | Driver’s door module |
| 33 | 20A | Front dual climate control module |
| 34 | 10A | Fuel filler flap lock |
| 35 | - | - |
| 36 | 5A | Battery back-up sounder/tilt sensor |
| 37 | 20A | Keyless vehicle module |
| 38 | 15A | Windshield wash pump relay |
| 39 | 25A | Left-side rear door module |
| 40 | 5A | Driver’s window, Clock, Switches around the Touch screen, Rear climate panel, Passenger door memory |
| 41 | 5A | Power amp |
| 42 | 30A | Driver's seat module |
| 43 | - | - |
| 44 | 25A | Right-side rear door module |
| 45 | 30A | Passenger front seat switch pack |
| 46 | 30A | Driver’s seat module |
| 47 | - | - |
| 48 | 30A | Left-side rear seat module |
| 49 | 5A | Right-side headlamp motor |
| 50 | 5A | Left-side headlamp motor |
| 51 | 5A | Steering wheel switches |
| 52 | 20A | Front cigar lighter |
| 53 | 20A | Rear cigar lighter |
| 54 | - | - |
| 55 | 20A | Rear accessory socket |
| 56 | 10A | Restraint control module, Occupancy sensor |
| 57 | 10A | Glovebox, glovebox lamp, front and rear overhead consoles, sun visor lamps, vanity lamps |
| 58 | 30A | Right-side rear seat module |
| 59 | - | - |
| 60 | - | - |
| 61 | 10A | Integrated antenna unit, cluster, cluster fan |
| 62 | 10A | Climate control module |
| 63 | 20A | Front accessory socket |
| 64 | 15A | Left-side rear sun blind |
| 65 | - | - |
| 66 | 5A | On-board diagnostic |
| 67 | - | - |
| 68 | - | - |
| 69 | 15A | Right-side rear sun blind |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | - | - |
| 2 |
10A 5A |
Engine management sensors Engine and E-box cooling fans |
| 3 | 25A | Ignition coils |
| 4 | 30A | Power wash pump |
| 5 | 40A | Main electrical power to module |
| 6 | 40A | Right-side front windshield heater and heated wiper |
| 7 | 30A | Traction control module (AWD) |
| 8 |
10A 5A |
Oxygen sensor Active engine mount |
| 9 | 10A | Engine cooling fan, Engine management |
| 10 | - | - |
| 11 | - | Spare |
| 12 |
20A 10A |
Oxygen sensors Bank A Engine management sensors |
| 13 | 20A | Oxygen sensors Bank B |
| 14 | 5A | Adaptive Cruise Control (ACC) |
| 15 | 20A | Oxygen sensors |
| 16 | - | Spare |
| 17 | - | - |
| 18 | 15A | Horn |
| 19 | 30A | Starter |
| 20 | 40A | Anti-lock Brake System (ABS) pumps |
| 21 | 25A | ABS valve |
| 22 | 15A | Left-side LED headlamps |
| 23 | 15A | Right-side LED headlamps |
| 24 | - | - |
| 25 | 15A | Intercooler water pump - EWP |
| 26 | 40A | Wiper motor |
| 27 | 5A | Monitor |
| 28 | 15A | Transmission control module |
| 29 | - | - |
| 30 | - | - |
| 31 | - | - |
| 32 | 40A | Left-side heated windshield |
| 33 | - | Spare |
| 34 | - | - |
| 35 | 80A | Cooling fan |
Luggage compartment fuse box A (Primary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 30A | Right-side Electric Parking Brake (EPB) |
| 2 | - | - |
| 3 | - | - |
| 4 | - | - |
| 5 | - | - |
| 6 | 30A | Power boot lid |
| 7 | - | - |
| 8 | 5A | Telematics |
| 9 | - | - |
| 10 | - | - |
| 11 | 20A | Front heated seat |
| 12 | 10A | Seat movement logic and switch power |
| 13 | 10A | Rear seat logic |
| 14 | 20A | Driver's heated seat |
| 15 | - | - |
| 16 | 10A | Chassis control module |
| 17 | 10A | Chassis control module (air suspension) |
| 18 | 10A | Infotainment Master Controller (IMC) fan |
| 19 | 30A | Fuel pump, Body control module, LSD |
| 20 | - | - |
| 21 | 10A | DiM |
| 22 | 10A | Headlamp control module, Camera, Lane change merge assist, Park aid module, Interior mirror |
| 23 | 5A | Adaptive Cruise Control (ACC) |
| 24 | 5A | GATEWAY |
| 25 | 5A | Air suspension module |
| 26 | 20A | Rear right-side Climate seat |
| 27 | 20A | Rear left-side Climate seat |
| 28 | - | - |
| 29 | - | - |
| 30 | 2A | VICS |
| 31 | - | - |
| 32 | 30A | Left-side EPB |
| 33 | 40A | E-diff module |
| 34 | 40A | Front blower motor |
| 35 | 60A | Quiescent relay box |
| 36 | 40A | Sunroof module |
| 37 | 60A | Air suspension |
| 38 | 40A | Power amp |
| 39 | - | - |
Luggage compartment fuse box B (Secondary):
| Fuse/Relay N° | Rating | Functions |
| 1 | 15A | Touch screen display |
| 2 | 10A | Amplifier, Clock |
| 3 | - | - |
| 4 | 10A | Phone connect view, Navigation, TV |
| 5 | 15A | Integrated audio module |
| 6 | 15A | Rear seat entertainment |
| 7 | - | - |
| 8 | - | - |
| 9 | - | - |
| 10 | - | - |
| 11 | -- | - |
| 12 | - | - |
| 13 | - | - |
| 14 | - | - |
| 15 | 15A | Heating and ventilation module |
| 16 | - | - |
