Kia Rio 2008 Fuse Box Info
Passenger fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| RR WIPER | 15A | Rear wiper |
| H/LP(LH) | 10A | Headlight (left) |
| FR WIPER | 25A | Front wiper |
| BLOWER | 10A | Blower |
| H/LP(RH) | 10A | Headlight (right) |
| S/ROOF | 20A | Sunroof |
| STOP LP | 15A | Stop light |
| C/DR LOCK | 20A | Central door lock |
| IGN COIL | 15A | Ignition coil |
| ABS | 10A | ABS |
| B/UP LP | 10A | Back-up light |
| SPARE | - | Spare fuse |
| C/LIGHTER | 25A | Cigar lighter |
| FOLD'G | 10A | Outside rearview mirror folding |
| HTD SEAT | 20A | Seat warmer |
| AMP | 25A | Amplifier |
| FR FOG LP | 10A | Front fog light |
| SPARE | - | Spare fuse |
| ECU | 10A | Engine control unit |
| CLUSTER | 10A | Cluster |
| P/WDW RH | 25A | Power window (right) |
| AUDIO | 10A | Audio |
| RR FOG LP | 10A | Rear fog light |
| IGN | 10A | Ignition |
| HTD GLASS | 30A | Rear window defroster |
| A/BAG | 15A | Air bag |
| TCU | 10A | Automatic transaxle control |
| SNSR | 10A | Sensors |
| SPARE | - | Spare fuse |
| MULT B/UP | 10A | Cluster, ETACS, A/C, Clock, Room lamp |
| AUDIO | 15A | Audio |
| P/WDW LH | 25A | Power window (left) |
| HTD MIRR | 10A | Outside rearview mirror heater |
| TAIL LP(LH) | 10A | Taillight (left) |
| TAIL LP(RH) | 10A | Taillight (right) |
| HAZARD | 10A | Hazard warning light |
| T/SIG LP | 10A | Turn signal light |
| A/BAG IND | 10A | Air bag warning |
| START | 10A | Start motor |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| BATT_1 | 50A | Alternator, Battery |
| ECU A | 30A | Engine control unit |
| RAD | 30A | Radiator fan |
| COND | 30A | Condenser fan |
| ECU B | 10A | Engine control unit |
| SPARE | - | Spare fuse |
| HORN | 10A | Horn |
| IGN1 | 30A | Ignition |
| IGN2 | 40A | Ignition |
| BATT_2 | 30A | Alternator, Battery |
| MAIN | 120A | Alternator |
| MDPS | 80A | Power steering wheel |
| ABS1 | 40A | ABS |
| ABS2 | 40A | ABS |
| P/WDW | 30A | Power window |
| BLW | 40A | Blower |
| SPARE | - | Spare fuse |
| A/CON1 | 10A | Air conditioner |
| A/CON2 | 10A | Air conditioner |
| ECU D | 10A | Engine control unit |
| SNSR | 10A | Sensors |
| INJ | 15A | Injector |
| ECU C | 20A | Engine control unit |
| SPARE | - | Spare fuse |
| SPARE | - | Spare fuse |
| HORN | - | Horn relay |
| MAIN | - | Main relay |
| FUEL PUMP | - | Fuel pump relay |
| RAD FAN | - | Radiator fan relay |
| COND FAN2 | - | Condenser fan relay |
| FUEL HTR | - | Fuel filter heater relay |
| BLOWER | - | Blower motor relay |
| START | - | Start motor relay |
| COND FAN1 | - | Condenser fan relay |
| A/CON | - | Air conditioner relay |
