Kia Spectra 2002 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located in the driver-side kick panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay Name | Rating | Functions |
| ECU B+ | 10A | ECU, ECAT, Shift lock, Data link connector, Check connector |
| AUDIO | 10A | Audio, Auto clock, ETWIS |
| ABS | 10A | ABS |
| TURN LAMP | 10A | Turn lamp |
| STOP LAMP | 10A | Stop light |
| CIGAR LIGHTER | 15A | Cigar lighter |
| AIR BAG | 10A | Airbag |
| METER | 10A | Meter, Inhibitor S/W, Speed sensor, Back-up light, ETWIS |
| SEAT WARM | 15A | Seat warmer |
| FRONT WIPER | 20A | Front wiper & Washer |
| TCU IG 1 | 10A | ECAT, DRL |
Engine compartment fuse box:
| Fuse/Relay | Rating | Functions |
| 1 IGN 1 | 20A | Ignition S/W(IG1. ACC) |
| 2 ABS | 30A | ABS |
| 3 TNS | 30A | TNS relay |
| 4 IGN 2 | 30A | Ignition S/W (IG2. ST) |
| 5 STARTER | 20A | Starter |
| 6 | - | - |
| 7 COOLING | 30A | Cooling fan |
| 8 CON/FAN | 20A | Condenser fan |
| 9 STARTER | 10A | Starter, ECU, ECAT Cruise control |
| 10 BLOWER | 30A | Blower relay |
| 11 SR/ACC | 10A | Intake SW, AQS, DRL Cruise control |
| 12 | - | - |
| 13 HAZARD | 15A | Hazard switch |
| 14 D/LOCK | 25A | Door lock, Power window |
| 15 ABS | 30A | ABS |
| 16 S/ROOF | 15A | Sunroof |
| 17 P/WIN RH | 25A | Power window RH |
| 18 P/WIN LH | 25A | Power window LH |
| 19 RR WIPER | 15A | Rear wiper & Washer |
| 20 ROOM | 10A | Room lamp, ETWIS, Audio, Auto clock |
| 21 HEAD | 25A | Headlight, Generator |
| 22 IG COIL | 15A | ECU IG coil, Data link connector, Check connector |
| 23 | - | - |
| 24 FRT FOG | 10A | Front fog lamp |
| 25 OX SEN D | 10A | O2 Sensor down |
| 26 OX SEN U | 10A | O2 Sensor up |
| 27 FUEL PUMP | 10A | Fuel pump |
| 28 INJECTOR | 10A | Injector, ECU, Fuel pump relay |
| 29 A/CON | 10A | A/CON relay (magnet dutch) |
| 30 HTD MIR | 10A | Outside rearview mirror heater |
| 31 BTN | 30A | Stop, ECU B+ fuse |
| 32 | - | - |
| 33 | - | - |
| 34 TAIL RH | 10A | ECU, Position lamp RH, Tail lamp RH, License light |
| 35 TAIL LH | 10A | Position lamp LH, Tail lamp LH, Illumination lamp |
| 36 HEAD LOW | 15A | Headlight low |
| 37 HEAD HI | 15A | Headlight hi |
| 38 HORN | 15A | Horn |
| 39 DEFOG | 30A | Rear defroster |
