Kia Spectra 2008 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel, behind the cover.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay Name | Rating | Functions |
| START | 10A | Start motor |
| SRF/D_LOCK | 20A | Sunroof, Door lock |
| HAZARD | 10A | Hazard warning flasher |
| A/CON | 10A | Air conditioner |
| CLUSTER | 10A | Cluster |
| RKE | 10A | Remote keyless entry |
| S/HTR | 20A | Seat warmer |
| C/LIGHTER | 15A | Cigar lighter |
| A/BAG | 15A | Airbag |
| R/WIPER | 15A | Rear wiper |
| AUDIO | 10A | Audio |
| ABS | 10A | Anti-lock brake system |
| ACC/PWR | 15A | Accessory / Power socket |
| ROOM | 15A | Room lamp |
| IGN | 10A | Ignition |
| ECU | 10A | Engine control unit |
| TAIL RH | 10A | Tail light (right) |
| T/SIG | 10A | Turn signal light |
| RR/HTR | 30A | Rear window defroster |
| P/WDW LH | 25A | Power window (left) |
| HTD/MIRR | 10A | Outside rearview mirror heater |
| P/WDW RH | 25A | Power window (right) |
| TAIL LH | 10A | Tail light (left) |
| RR/HTR | - | Rear window defroster relay |
| RESISTOR | - | Resistor |
| P/WDW | - | Power window relay |
| POWER | - | Accessory / Power socket relay |
| TAIL | - | Tail light relay |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| ATM | 20A | Automatic transaxle control |
| ECU1 | 10A | Engine control unit |
| STOP | 15A | Stop light |
| F/WIPER | 20A | Front wiper |
| R/FOG | 10A | Rear fog light |
| F/FOG | 15A | Front fog light |
| LO HDLP | 15A | Headlight (low) |
| HI HDLP | 15A | Headlight (high) |
| A/CON | 10A | Air conditioner |
| F/PUMP | 15A | Fuel pump |
| T/OPEN | 10A | Trunk lid opener |
| FOLD | 10A | Outside rearview mirror folding |
| HORN | 10A | Horn |
| DEICE | 15A | Deicer |
| INJ | 15A | Injection |
| SNSR | 10A | O2 sensor |
| ECU2 | 30A | Engine control unit |
| SPARE | 10A | spare fuse |
| SPARE | 15A | spare fuse |
| SPARE | 20A | spare fuse |
| SPARE | 30A | spare fuse |
| ABS2 | 30A | Anti-lock brake system |
| ABS1 | 30A | Anti-lock brake system |
| IP B+ | 50A | In panel B+ |
| BLOWER | 30A | Blower |
| IGN2 | 30A | Ignition |
| IGN1 | 30A | Ignition |
| RAD | 30A | Radiator fan |
| COND | 20A | Condenser fan |
| ALT | 120A | Alternator |
| ATM | - | Automatic transaxle control relay |
| WIPER | - | Wiper relay |
| F/FOG | - | Front fog light relay |
| LO HDLP | - | Headlight relay (low) |
| HI HDLP | - | Headlight relay (high) |
| A/CON | - | Air conditioner relay |
| F/PUMP | - | Fuel pump |
| DRL | - | Daytime running light relay |
| COND2 | - | Condenser fan relay |
| HORN | - | Horn relay |
| MAIN | - | Main relay |
| START | - | Start motor relay |
| RAD | - | Radiator fan relay |
| COND | - | Condenser fan relay |
