Kia Magentis 2007 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box::
| Fuse/Relay Name | Rating | Functions |
| H/LP | 10A | Headlight |
| A/CON SW | 10A | Air conditioner |
| START | 10A | Start motor |
| P/SEAT RH | 30A | Power seat (right) |
| P/WDW RH | 25A | Power window (right) |
| WIPER | 25A | Front wiper |
| MIRR HTD | 10A | Outside rearview mirror defroster |
| RR FOG | 15A | Rear fog light |
| P/SEAT LH | 30A | Power seat (left) |
| P/WDW LH | 25A | Power window (left) |
| SPARE | 10A | Spare fuse |
| MODULE-2 | 10A | Cluster |
| W/DEICER | 15A | Deicer |
| TAIL RH | 10A | Taillight (right) |
| TAIL LH | 10A | Taillight (left) |
| EPS | 10A | Power steering wheel |
| A/CON | 10A | Air conditioner |
| SAFETY PWR | 20A | Safety power window |
| A/BAG IND | 10A | Airbag warning |
| A/BAG | 15A | Airbag |
| DR LOCK | 25A | Central door lock |
| SPARE | 10A | Spare fuse |
| CLUSTER | 10A | Cluster |
| MODULE-1 | 10A | BWS buzzer, ESP switch |
| HAZARD | 15A | Hazard warning light |
| STOP LP | 15A | Stop light |
| SPARE | 15A | Spare fuse |
| TELL TALE | 10A | Clock |
| T/LID OPEN | 15A | Trunk lid opener |
| ADJ PEDAL | 10A | Adjust pedal relay |
| SPARE | 15A | Spare fuse |
| T/SIG | 10A | Turn signal light |
| TPMS | 10A | TPMS |
| BLOWER MTR | 10A | Blower, Air conditioner |
| MEMORY | 15A | Cluster, ETACS, A/C, Clock, Room lamp |
| AUDIO | 15A | Audio |
| C/LIGHTER | 25A | Cigar lighter |
| D/CLOCK | 10A | Clock |
Engine compartment fuse box:
| Fuse/Relay Name | Rating | Functions |
| I/P B+ 2 | 50A | In panel B+ |
| ABS 2 | 40A | ABS |
| DRL | 15A | Daytime running light |
| HORN | 15A | Horn |
| H/LP LOW | 15A | Headlight (low) |
| F/PUMP | 20A | Fuel pump |
| H/LP HI | 15A | Headlight (high) |
| ECU | 10A | Engine control unit |
| ABS 1 | 40A | ABS |
| ALT | 125A (150A) | Alternator |
| SPARE | 10A | Spare fuse |
| SPARE | 15A | Spare fuse |
| SPARE | 20A | Spare fuse |
| FRT FOG | 15A | Front fog light |
| ECU RELAY | 30A | Engine control unit |
| POWER AMP | 20A | Amplifier |
| SPARE | 15A | Spare fuse |
| SPARE | 20A | Spare fuse |
| P/OUTLET | 25A | Power outlet |
| RAD FAN | 30A (40A) | Radiator fan |
| PCU | 10A | Power train control system sensors, TCU |
| ABS | 10A | ABS |
| S/WARMER | 25A | Seat warmer |
| ATM | 20A | Automatic transaxle control |
| S/ROOF | 20A | Sunroof |
| SPARE | 20A | Spare fuse |
| BACK UP | 10A | Back-up light |
| RR HTD | 40A | Rear window defroster |
| IGN 1 | 30A | Ignition |
| B+ | 30A | In pannel B+ |
| TAIL | 20A | Taillight |
| A/CON | 10A | Air conditioner |
| ECU-1 | 20A | Engine control unit |
| IGN COIL | 20A | Ignition coil |
| SNSR 3 | 10A | Sensors |
| BLOWER | 40A | Blower |
| IGN 2 | 30A | Ignition |
| SNSR 2 | 15A | Sensors |
| SNSR 1 | 15A | Sensors |
| HORN RELAY | - | Horn relay |
| HDLP_LOW RELAY | - | Headlight (low) relay |
| RAD FAN_HI RELAY | - | Radiator fan relay |
| RAD FAN_LOW RELAY | - | Radiator fan relay |
| F/PUMP RELAY | - | Fuel pump relay |
| WIPER RELAY | - | Wiper relay |
| MAIN RELAY | - | Main relay |
| START RELAY | - | Start motor relay |
| ATM CONT RELAY | - | Automatic transaxle control relay |
| A/CON RELAY | - | Air conditioner relay |
