Holden Viva 2009 Fuse Box Info
Passenger compartment fuse box location:
The instrument panel fuse box is located on the end of the instrument panel on the driver’s side of the vehicle.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| 1 | 10A | AUDIO/CLOCK |
| 2 | 15A | EXTRA JACK |
| 3 | 15A | CIGAR LIGHTER |
| 4 | 10A | BACK-UP |
| 5 | 15A | REAR FOG |
| 6 | 15A | ATC/CLOCK |
| 7 | 15A | AUDIO |
| 8 | 10A | IMMOBILISER |
| 9 | 25A | WIPER |
| 10 | - | SPARE |
| 11 | 10A | ABS |
| 12 | 10A | IMMOBILISER |
| 13 | 10A | TCM |
| 14 | 15A | HAZARD |
| 15 | 15A | ANTI-THEFT |
| 16 | 10A | DIAGNOSIS |
| 17 | 10A | AIRBAG |
| 18 | 10A | ECM |
| 19 | 15A | TURN SIGNAL |
| 20 | 10A | CLUSTER |
| 21 | - | SPARE |
| 22 | 10A | ENGINE FUSE |
| 23 | 20A | HVAC |
| 24 | 15A | SUNROOF |
Engine compartment fuse box:
| Fuse/Relay N° | Rating | Functions |
| Fuses | ||
| 1 | 15A | DIS |
| 2 | 10A | ECM |
| 3 | 25A | HEADLAMP |
| 4 | 15A | STOP |
| 5 | 20A | DR’S P/WDO |
| 6 | 15A | H/L HL |
| 7 | 15A | HORN |
| 8 | 10A | A/C |
| 9 | 15A | FUEL PUMP |
| 10 | 15A | PASS F/BOX |
| 11 | 10A | H/L LO LH |
| 12 | 15A | RMS |
| 13 | 15A | INJECTOR |
| 14 | 10A | IL LH |
| 15 | 15A | FOG |
| 16 | 10A | MIR. HEAT |
| 17 | 15A | DOOR LOCK |
| 18 | 30A | BATT MAIN |
| 19 | 60A | ABS |
| 20 | 30A | BLOWER MOTOR |
| 21 | 30A | IGN-2 |
| 22 | 10A | H/L LO RH |
| 23 | 10A | IL RH |
| 24 | 20A | ELEC FAN LO |
| 25 | 30A | DEFOG |
| 26 | 30A | ELEC FAN HI |
| 27 | 20A | POWER WINDOW |
| 28 | 30A | IGN-1 |
| 29 | - | SPARE |
| 30 | - | SPARE |
| 31 | - | SPARE |
| Relays | ||
| 1 | - | ELEC FAN LO RELAY |
| 2 | - | FRT FOG RELAY |
| 3 | - | ILLUMINATION RELAY |
| 4 | - | A/C COMP RELAY |
| 5 | - | HORN RELAY |
| 6 | - | DEFOG RELAY |
| 7 | - | FUEL PUMP RELAY |
| 8 | - | MAIN RELAY |
| 9 | - | ELEC FAN HI RELAY |
| 10 | - | POWER WINDOW RELAY |
| 11 | - | HEAD LAMP RELAY |
