Mercury Villager 1996 Fuse Box Info
Passenger compartment fuse box location:
The fuse box is located at the left side of the steering column at the bottom of the instrument panel.
Engine compartment fuse box location:
Fuse Box Diagram | Layout
Passenger compartment fuse box:
| Fuse/Relay N° and Name | Rating | Functions |
| 1. Open | - | Not Used |
| 2. Electron | 10A | A/C (Air Conditioning), Timer Module |
| 3. Airbag | 10A | Air Bag |
| 4. Engine Cont | 10A | Engine Emissions, Evaporative Emissions, Powertrain Control Module (PCM) |
| 5. Mirror | 10A | Power Mirror, Timer Module |
| 6. Cigar Lighter | 20A | Cigar Lighter |
| 7. Rear Power Plug | 20A | Rear Power Plug |
| 8. Front Wiper | 20A | Front Windshield Wiper/Washer |
| 9. Rear Wiper | 10A | Rear Window Wiper/Washer |
| 10. Audio | 7.5A | Radio, Power Antenna, Rear Integrated Control Panel (RICP) |
| 11. Audio Amp | 20A | Subwoofer Amplifier |
| 12. Electron | 7.5A | Powertrain Control Module (PCM) |
| 13. A/C Cont | 7.5A | A/C, Auto Light, Rear Defrost Switch |
| 14. Rear Defog | 20A | Rear Defrost |
| 15. Rear Defog | 20A | Rear Defrost |
| 16. Heated Mirror | 20A | Heated Power Outside Side View Mirrors |
| 17. Corner L | 10A | Cornering Lamp |
| 18. I/P Ilum | 7.5A | Instrument Illumination, Radio Illumination |
| 19. Tail Lamp | 10A | Tail Lamp, Rear Parking Lights |
| 20. Audio | 10A | CD, Power Antenna, Radio |
| 21. Room Lamp | 15A | Dome Lamps, Step Lamps, Warning Chime |
| 22. Stop Lamp | 15A | Shift-Lock Solenoid, Stoplamps |
| 23. Hazard | 10A | Hazard Flasher |
| 24. Rear Blower | 15A | Rear Blower Motor |
| 25. Rear Blower | 15A | Rear Blower Motor |
| 26. Open | - | Not Used |
| 27. Turn | 10A | Turn Signal Lamps |
| 28. Front Blower | 20A | Front Blower Motor |
| 29. Relays | 10A | Relays in Main Fuse Junction Panel |
| 30. Electron | 10A | Anti-lock Brakes (ABS), Backup Lamps, Overdrive Off Lamp, PRND Switch |
| 31. Front Blower | 20A | Front Blower Motor |
| 32. Open | - | Not Used |
| 33. Accessory Relay #1 | - | Fuses 17,18,19 |
| 34. Ignition Relay | - | Fuses 26, 27, 29, 30 |
| 35. Accessory Relay #2 | - | Fuses 5, 6, 7, 8, 9 |
| 36. Rear Defrost Relay | - | Fuses 14,15,16 |
| 37. Blower Relay | - | Fuses 28, 31 |
Engine compartment fuse box:
| Fuse/Relay N° and Name | Rating | Functions |
| 1. RAD FAN LO | - | Cooling Fan (Low Speed) |
| 2. RAD FAN HI 1 | - | Cooling Fan (Medium Speed) |
| 3. RAD FAN HI 2 | - | Cooling Fan (High Speed) |
| 4. POWER WINDOW | 30A | Power Seat, Power Window, Sun Roof |
| 5. ABS | 30A | Anti-lock Brake Control Module |
| 6. RAD FAN | 65A | Cooling Fan |
| 7. FRONT BLOWER | 65A | Front Blower Motor |
| 8. MAIN | 100A | Hazard Lamps, Interior Illumination, Radio, Stoplamps, Transmission Control Module |
| 9. ALT | 120A | Mini Fuse Portion of Main Fuse Junction Panel |
| 10. RR DEF | 45A | Heated Mirrors, Heated Rear Window, Rear Blower Motor |
| 11. IGN SW | 30A | Ignition Switch |
| 12. OPEN | - | Not Used |
| 13. OPEN | - | Not Used |
| 14. H/L RH | 15A | Right-Hand Headlamp |
| 15. H/L LH | 15A | Left-Hand Headlamp |
| 16. ALT | 10A | Alternator Input |
| 17. ENG CONT | 10A | Powertrain Control Module (PCM) Relay |
| 18. INJ | 10A | Fuel Injectors |
| 19. FUEL PUMP | 15A | Fuel Pump Relay |
| 20. HORN | 15A | Horn Relay |
| 21. ABS | 20A | Anti-lock Brake Hydraulic Actuator |
| 22. HOOD LAMP | 15A | Hood Illumination Lamp |
| 23. S.E.C. | 7.5A | Keyless Entry Beeper, Timer Module |
| 24. HORN | - | High Horn, Low Horn |
| 25. FUEL PUMP | - | Fuel Pump |
| 26. INHIBIT | - | Starter Motor |
| 27. HEADLAMP RH | - | Right-Hand Headlamp |
| 28. BULB CHECK | - | Brake Warning Lamp, Charge Warning Lamp |
| 29. ASCD HOLD | - | Speed Control Module |
Engine compartment relay box:
| Relay N° | Rating | Functions |
| 1 | - | Antitheft (Interrupt) |
| 2 | - | Headlamp LH |
| 3 | - | Blank |
| 4 | - | FICD |
| 5 | - | Auto Light Headlamp/Antitheft Headlamp |
| 6 | - | Air Conditioner |
